Swing-Out Rack Mounts | Patch & Splice Rack Mounts | Wall Mounts | Snap Packs | Pigtail Packs | Cassettes | Splice Trays | Adapter Panels RACK MOUNT, WALL MOUNT ENCLOSURES & ACCESSORIES Product Buyers Guide | 2nd Edition Fiber Optic Enclosure Product Line YOUR FIBER OPTIC ENCLOSURE SOLUTION
Private Label / OEM Enclosures 1-800-5000-FIS(347) www.fiberinstrumentsales.com For more information, reach out to your FIS sales representative or FIS Interconnect PLM Steve Ermacor 315-737-2123 | sermacor@fissales.com • Supplied Vector File • 50 Piece MOQ (Mix/Match) • $250 One Time Set Up Fee REQUIREMENTS • Logo • Colors • Enclosure Design CUSTOM OPTIONS Are you looking for fiber enclosures but don’t want another companies’ logo on there? Maybe you need a specific enclosure that you can’t find anywhere?... Well look no further. FIS is here to help! All FIS bent metal enclosures, both ISP and OSP are manufactured right here in Upstate NY. Having all of our enclosures made in house puts us in a unique position that allows us to modify existing or design a new, custom enclosure to meet customer needs. Our OEM capabilities include but are not limited to silk screened customer logos, company colors and custom labeling. We can also incorporate features such specific dimensions, face plates, cable management and more. We also offer pre-loaded solutions. Have your stock or custom enclosure loaded here at FIS prior to shipment. Pre-loaded options include adapter plates, pigtails, splice trays and feeder cables. Having your enclosures pre-loaded cuts down on labor and installation time. Whether you’re looking for a solution indoors or in the elements FIS has you covered.
Product Buyers Guide FIS Fiber Optic Enclosure Product Line Factory Preloaded Fiber Interconnects www.fiberinstrumentsales.com FOR OUR FULL LINE OF PRODUCT OFFERINGS Sales Representatives Are Waiting For Your Call! 1-800-5000-FIS(347) We Stock Enclosures, Pigtails, Splice Trays, & Adapter Plates 1, 2 & 4 RU Slide-Out Rack Mounts Economy and Deluxe Wall Mounts ∙ Faster Field Installations ∙ Quick Turnaround ∙ Small or Large Quantity Orders ∙ Save Labor in the Field ∙ Technical Drawings Available Advantages ∙ Swing-out Rack Mounts ∙ Slide-out Rack Mounts ∙ Compact Wall Mounts ∙ Economy Wall Mounts ∙ Deluxe Wall Mounts Fiber Optic Solutionists Fiber Instrument Sales, Inc. Table Of Contents 1RU or 4RU 19" Flush Mount Patch Panel Frame..................1 Flush Mount Panels.................................................................2 Cable Lacing Shelf...................................................................3 Universal Rack Mount 1RU and 2RU Swing-Out Patch Panels............................................................................4 Cabinet Fiber Interconnect with Swing Out Panel & Cable Manager.........................................................................5 4RU & 8RU Rack Mount Patch & Splice Panel Frame............6 1RU Rack Mount Enclosure. ...................................................7 2RU Rack Mount Enclosure. ...................................................8 4RU Rack Mount Enclosure. ...................................................9 8RU Rack Mount Enclosure. ...................................................10 1RU Slack Cable Management Enclosure..............................11 1RU High Density Breakout Cassette Enclosure. ..................12 High Density Breakout Cassette.............................................13 1RU High Density Rack Mount Enclosure..............................15 4X SHD Breakout Cassette.....................................................16 Intelligent Transportation System (ITS) Cabinet Closure. .... 18 Compact Wall Mount, 1 Adapter Plate...................................19 Compact Wall Mount, 2 Adapter Plate...................................20 Zone Electrical Box Outlet Enclosure.....................................21 Mini Wall Mount Enclosure.....................................................22 Economy Wall Mount Enclosure.............................................23 2 or 4 Panel Deluxe Wall Mount Enclosure.........................24 8 or 12 Panel Deluxe Wall Mount Enclosure.......................25 Deluxe Wall Mount Patch Panel...........................................26 Single Door Wall Mount........................................................ 27 Wall Mount Splice Enclosure............................................... 28 Inside Plant (ISP) Slack Box................................................. 29 Titan Wall Mount Enclosure................................................. 30 Titan Mini Wall Mount Enclosure......................................... 31 Fiber Optic Ceiling Mount Zone Enclosure. ........................32 Single Fiber Patch & Splice Cassette Kits...........................33 Mass Fusion (Ribbon) Patch & Splice Cassette Kits..........34 MTP Pre-Terminated Systems............................................. 35 Adapter Panels. .................................................................... 36 Universal Adapter Plate Bracket For Corning WCH, CCH, and EDC Closures........................................................ 39 Cassette Bracket For Corning WCH, CCH, PCH and EDC Closures................................................................. 40 Color-Coded 900µm Pigtail Packs. ..................................... 41 Color-Coded Distribution Style Pigtail Packs......................43 Snap Packs. .......................................................................... 45 12 or 24 Position Aluminum Splice Tray.............................47 L-Shaped Bracket.................................................................. 48 FIS Optical TAP Interface Panels......................................... 49
1 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line F1-FM4RU12X Adapter Plates & Cassettes Sold Separately 1RU or 4RU 19” Flush Mount Patch Panel Frame The FIS 1RU 19” Flush Mount Patch Panel Frame accommodates (3) LGX Adapter Plates, Modules or Cassettes. The FIS 4RU 19” Flush Mount Patch Panel Frame accommodates (12) LGX Adapter Plates, Modules or Cassettes. The flush mount design attaches flat against the rack to save space in compact applications. Patch panel frame installs into a standard 19” rack with included mounting hardware. Adapter plates sold separately. • 19” Rack Mountable Patch Panel • Flush Mount • 1RU Holds (3) LGX Adapter Plates, Modules or Cassettes • 4RU Holds (12) LGX Adapter Plates, Modules or Cassettes • Rugged 14 Gauge Aluminum, Black FEATURES 1RU FLUSH MOUNT PATCH PANEL SPECS 4RU FLUSH MOUNT PATCH PANEL SPECS Dimensions 19”W x 7”H 19”W x 7”H Compatible Rack Width 19” Wide Telco Racks 19” Wide Telco Racks Capacity (3) LGX Adapter Plates, Modules, or Cassettes (12) LGX Adapter Plates, Modules, or Cassettes Material .060” Aluminum .060” Aluminum Coating Electro Statically Applied Powder Coat Available in Black Electro Statically Applied Powder Coat Available in Black Weight 0.60 lbs PART# DESCRIPTION PRICE F1FM1RU3X 1RU 19” Flush Mount Patch Panel Frame, Unloaded $20.00 F1FM4RU12X 4RU 19” Flush Mount Patch Panel Frame, Unloaded $39.95
2 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line F1FMP1RULCUPC96* * 1RU Flush Mount Panels Sold Separately Flush Mount Panels The FIS 1RU Flush Mount Panel is designed to patch fiber optic cables within a rackmount or cabinet. The high density of each panel allows you to maximize your rack space. Its recommended to use these panels in conjunction with the FIS 1RU Lacing Shelf. • Simplex SC Bulkheads • Duplex LC Bulkheads • Zirconia Ceramic Sleeves • Supports Singlemode and Multimode • Numbered Ports • Optional Lacing Shelf FEATURES PART# DESCRIPTION PRICE F1FMP1RUSCUPC24 FIS Flush Mount Panel 1RU SC/UPC, 24 ports $80.00 F1FMP1RUSCAPC24 FIS Flush Mount Panel 1RU SC/APC, 24 ports $80.00 F1FMP1RUSC10GIG24 FIS Flush Mount Panel 1RU OM3/OM4, 24 ports $80.00 F1FMP1RUSCUPC48 FIS Flush Mount Panel 1RU SC/UPC, 48 ports $105.00 F1FMP1RUSCAPC48 FIS Flush Mount Panel 1RU SC/APC, 48 ports $105.00 F1FMP1RUSC10GIG48 FIS Flush Mount Panel 1RU OM3/OM4, 48 ports $105.00 PART# DESCRIPTION PRICE F1FMP1RULCUPC48 FIS Flush Mount Panel 1RU LC/UPC, 48 ports $105.00 F1FMP1RULCAPC48 FIS Flush Mount Panel 1RU LC/APC, 48 ports $105.00 F1FMP1RULC10GIG48 FIS Flush Mount Panel 1RU OM3/OM4, 48 ports $105.00 F1FMP1RULCUPC96 FIS Flush Mount Panel 1RU LC/UPC, 96 ports $131.50 F1FMP1RULCAPC96 FIS Flush Mount Panel 1RU LC/APC, 96 ports $131.50 F1FMP1RULC10GIG96 FIS Flush Mount Panel 1RU OM3/OM4, 96 ports $131.50 PART# DESCRIPTION PRICE F11RULACINGSHELF* FIS 1RU Lacing Shelf, 6” Deep $27.50 F1FMP1RULC10GIG48 Width 19” Height 1.75” Materials 16 Gauge CRS (Cold Rolled Steel) Color/Finish Black Powder Coat Finish
3 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line F11RULACINGSHELF F1FMP1RULCUPC96* * 1RU Flush Mount Panels Sold Separately Cable Lacing Shelf The FIS 1U Cable Lacing Shelf is no ordinary shelf. It is designed to offer a supportive surface for cables when securing, routing, and organizing connection points to and from switches, patch panels, and other rackmount equipment. For versatile mounting, the 1U Cable Lacing Shelf can be placed above, below, behind, or in front of your network devices. As a result, valuable rack space is made available for other rack configuration needs. Managing cables on this lacing shelf is easy with the help of the Hook and Loop Cable Ties. Simply bundle cables to the 1U Cable Lacing Shelf with the Hook and Loop Cable Ties to add support, organization, and protection to your network cabling. • Swing Out Shelf • 6”depth • Supports up to 10lbs of cables FEATURES • Multiple tie off points • Versatile mounting • Reduces bend radius Width 19” Depth 6” Height 1.72” Materials CRS (Cold Rolled Steel) Color/Finish Black Powder Coat Finish Weight 2.00 lbs. PART# DESCRIPTION PRICE F1-1RULACINGSHELF FIS 1RU Lacing Shelf, 6” Deep $27.50
4 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Universal Rack Mount 1RU and 2RU Swing-Out Patch Panels Product Buyers Guide FIS Fiber Optic Enclosure Product Line F1-RMSO1RU2X The 1RU FIS Swing Out Patch Panel accommodates (2) LGX adapter plates, and the 2RU model supports (4) LGX adapter plates, modules or cassettes. It is designed to house fiber terminations and accommodate patching of fiber links. The swing-out design offers easy access to cable and splices located in the patch and splice bay. Multiple cable retention brackets and tie down spots allow for convenient cable management. These units can be flush mounted or mounted with 3.5” protrusion from the rack with no additional accessories. Rack mount installs into a standard 19” rack with included mounting hardware. Adapter panels and 23” mounting brackets are sold separately. • Swing Out Shelf • 1RU Holds (2) LGX Adapter Plates, Cassettes, or Modules • 2RU Holds (4) LGX Adapter Plates, Cassettes, or Modules • Multiple Tie Downs and Cable Retention Brackets • Flush Mount or 3.5” Protrusion; No Accessories Required • Rugged 14 Gauge Aluminum, Available in Black or Off-White (BW) • Order Preloaded with Terminated Cables, Adapters, Pigtails, Splice Trays or Cassettes 1RU & 2RU FEATURES 1RU RACK MOUNT SPECS 2RU RACK MOUNT SPECS Dimensions (in) 17”W x 11.5” D x 1.75”H 17”W x 11.5” D x 3.5”H Capacity Up to 12 (6 Pack) or 16 (8 Pack) Simplex Connections Up to 24 (6 Pack) Duplex Connections (LC or SC) Up to 24 (6 Pack) or 32 (8 Pack) Simplex Connections Up to 48 (6 Pack) Duplex Connections (LC or SC) Material .060” Aluminum .060” Aluminum Coating Electro-statically Applied Powder Coat Available in Black or Off White Electro-statically Applied Powder Coat Available in Black or Off White F1-RMSO2RU4X PART# DESCRIPTION PRICE F1-RMSO1RU2X 1RU Swing Out Enclosure, 2 Plate Capacity, Black, Unloaded $105.00 F1-RMSO1RU2X-BW 1RU Swing Out Enclosure, 2 Plate Capacity, Off White, Unloaded $105.00 F1-RMSO2RU4X 2RU Swing Out Enclosure, 4 Plate Capacity, Black, Unloaded $110.00 F1-RMSO2RU4X-BW 2RU Swing Out Enclosure, 4 Plate Capacity, Off White, Unloaded $110.00 RACK-ADP23 1RU and 2RU 23” Rack Mounting Brackets, Pair, Black $14.95 RACK-ADP23BW 1RU and 2RU 23” Rack Mounting Brackets, Pair, Off White $14.95 F1-SPL12 Metal Splice Tray, 12 Position Fusion Splice Chip, 6.5”L x 4.7”W x .42”H $17.95 F1-SPL24-8.5 Metal Splice Tray, 24 Position Fusion Splice Chip, 8.5”L x 5.06”W x .42”H $18.95 F1-6707BLKF Metal Splice Tray, 12 Position Fusion Splice Chip, 7.5”L x 4”W x .63”H $14.95 Shown with SC/APC Adapters Shown with SC/APC Adapters
5 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line F1RMRX2RU4X Cabinet Fiber Interconnect with Swing Out Panel & Cable Manager Designed to provide front entrance cabinet users access to the rear of fiber interconnect connectors with use of swing out panel. Includes a splice tray riser and two 24 fiber fusion splice trays. The attached side cable manager can accommodate cables or allow rear exit to the back of the cabinet where often chimneys are installed for routing cables from different bays. Interconnect utilizes standard LGX footprint adapter panels. Optional front lacing bar can dress cables to cable manager and secure them from being snagged or pinched in cabinet door. • Flush mount • Holds (4) LGX adapter plates • Fully removable lid • Left side cable manager • (2) 24 strand splice trays included • Cable management accessories included FEATURES Dimensions 3.5” H x 18.20” W x 10.42” D Material .060” Aluminum Coatings Electro-statically Applied Powder Coat, Available in Black PART# DESCRIPTION PRICE F1RMRX2RU4X FIS Flush mount 2RU Swing Out Enclosure, Left Side Cable Manager and Rear Exit Cable Return, Unloaded $125.00 F1RMRX2RU4XLB Lacing Bar Accessory for F1RMRX2RU4X, 11.50” L x 1.25” D $15.00 PART# DESCRIPTION PRICE RACK-ADP23 1RU and 2RU 23” Rack Mounting Brackets, Pair, Black $14.95 RACK-ADP23BW 1RU and 2RU 23” Rack Mounting Brackets, Pair, Off White $14.95 F1-SPL12 Metal Splice Tray, 12 Position Fusion Splice Chip, 6.5”L x 4.7”W x .42”H $17.95 F1-SPL24 Metal Splice Tray, 24 Position Fusion Splice Chip, 11.72”L x 3.99”W x .42”H $18.95 F1-SPL24XL Aluminum Splice Tray, 24 Position, XL, Fusion Splice Chip, Rigid, 10"L x 5"W x 0.41"H $22.95 F1-6707BLKF Metal Splice Tray, 12 Position Fusion Splice Chip, 7.5”L x 4”W x .63”H $14.95
6 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 4RU & 8RU Rack Mount Patch & Splice Panel Frame The 4RU FIS Patch and Splice Panel accommodates (4) LGX adapter panels, modules or cassettes and the 8RU accommodates (12) LGX adapter panels, modules or cassettes. The 2 sliding trays on the top and bottom of the enclosure allow for easy access to both the patch bay and splice bay. Multiple cable retention brackets, splice tray mounts and tie down spots allow for convenient cable management. Rack mount installs into a standard 19” rack with included mounting hardware. Adapter panels, splice trays and 23” mounting brackets are sold separately. • 4RU Holds (4) LGX Adapter Plates, Cassettes, or Modules • 8RU Holds (12) LGX Adapter Plates, Cassettes, or Modules • (2) Slide Out Trays with Spring Loaded Stop Latch • Built In Raised Splice Tray Mounting Bracket • Multiple Tie Downs and Cable Retention Brackets • Hinged Front and Rear Removable Doors, Lexan Doors Available • Rugged 14 Gauge Aluminum, Available in Black or Off-White (BW) • Order Preloaded with Terminated Cables, Adapters, Pigtails, Splice Trays or Cassettes 4RU & 8RU FEATURES Product Buyers Guide FIS Fiber Optic Enclosure Product Line F1-RMSP4RU4X F1-RMSP8RU12X 4RU PATCH & SPLICE RACK MOUNT SPECS 8RU PATCH & SPLICE RACK MOUNT SPECS Dimensions (in) 17”W x 14”D x 7.125”H 17”W x 14”D x 14”H Weight Up to 24 (6 Pack) or 32 (8 Pack) Simplex Connections Up to 48 (6 Pack) Duplex Connections (LC or SC) Up to 72 (6 Pack) or 96 (8 Pack) Simplex Connections Up to 144 (6 Pack) Duplex Connections (LC or SC) Material .060” Aluminum .060” Aluminum Coating Electro-statically Applied Powder Coat Available in Black or Off White Electro-statically Applied Powder Coat Available in Black or Off White PART# DESCRIPTION PRICE F1RMSP4RU4X 4RU Patch and Splice Enclosure, 4 Plate Capacity, Solid Front/Rear Doors, Black $240.00 F1RMSP4RU4XL 4RU Patch and Splice Enclosure, 4 Plate Capacity, Smoked Lexan Front/Solid Rear Door, Black $245.00 F1RMSP4RU4X-BW 4RU Patch and Splice Enclosure, 4 Plate Capacity, Solid Front/Rear Doors, Off White $240.00 F1RMSP4RU4XL-BW 4RU Patch and Splice Enclosure, 4 Plate Capacity, Smoked Lexan Front/Solid Rear Door, Off White $245.00 F1RMSP8RU12X 8RU Patch and Splice Enclosure, 12 Plate Capacity, Solid Front/Rear Doors, Black $252.00 F1RMSP8RU12XL 8RU Patch and Splice Enclosure, 12 Plate Capacity, Smoked Lexan Front/Solid Rear Door, Black $265.00 F1RMSP8RU12X-BW 8RU Patch and Splice Enclosure, 12 Plate Capacity, Solid Front/Rear Doors, Off White $252.00 F1RMSP8RU12XL-BW 8RU Patch and Splice Enclosure, 12 Plate Capacity, Smoked Lexan Front/Solid Rear Door, Off White $265.00 F1-SPL12 Metal Splice Tray, 12 Position Fusion Splice Chip, 6.5”L x 4.7”W x .42”H $17.95 F1-SPL24 Metal Splice Tray, 24 Position Fusion Splice Chip, 11.72”L x 3.99”W x .42”H $18.95 F1-SPL24-8.5 Metal Splice Tray, 24 Position Fusion Splice Chip, 8.5”L x 5.06”W x .42”H $18.95 F1-SPL24XL Aluminum Splice Tray, 24 Position, XL, Fusion Splice Chip, Rigid, 10"L x 5"W x 0.41"H $22.95 F1-6707BLKF Metal Splice Tray, 12 Position Fusion Splice Chip, 7.5”L x 4”W x .63”H $14.95 F1-13189 Cable Retention Rings For 4RU & 8RU Interconnect - 10 pack $7.95
7 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line F1-RM1RU3X Adapters Plates Sold Separately 1RU Rack Mount Enclosure The 1RU FIS Rack Mount Enclosure provides many flexible configurations in a 1RU form factor. It accommodates (3) LGX adapter plates, modules or cassettes. Slide out trays and removable front and back doors allow easy access to the patch bay. Multiple cable retention brackets and tie down spots allow for convenient cable management. Spring loaded stop latches keep the tray securely in place when retracted. Rack mount installs into a standard 19” rack. Adapter plates, 23” mounting brackets and 19” flush mounting brackets are sold separately. • Slide Out Tray with Spring Loaded Stop Latch • Holds (3) LGX Adapter Plates, Cassettes, or Modules • Multiple Tie Downs and Cable Retention Brackets • Hinged Front and Rear Removable Doors • Rugged 14 Gauge Aluminum, Available in Black or Off-White (BW) • Order Preloaded with Terminated Cables, Adapters, Pigtails, Splice Trays or Cassettes FEATURES Dimensions 17”W x 14”D x 1.75”H Capacity Up to 18 (6 Pack) or 24 (8 Pack) Simplex Connections Up to 36 (6 Pack) Duplex Connections (LC or SC) Material .060” Aluminum Coating Electro Statically Applied Powder Coat; Available in Black or Off-White PART# DESCRIPTION PRICE F1-RM1RU3X 1RU Rack Mount, 3 Plate Capacity, Solid Front/Rear Doors, Black $134.00 F1-RM1RU3X-BW 1RU Rack Mount, 3 Plate Capacity, Solid Front/Rear Doors, Off White $134.00 RACK-ADP23 1RU and 2RU 23” Rack Mounting Brackets, Pair, Black $14.95 RACK-ADP23BW 1RU and 2RU 23” Rack Mounting Brackets, Pair, Off White $14.95 F1-SPL12 Metal Splice Tray, 12 Position Fusion Splice Chip, 6.5”L x 4.7”W x .42”H $17.95 F1-SPL24 Metal Splice Tray, 24 Position Fusion Splice Chip, 11.72”L x 3.99”W x .42”H $18.95 F1-SPL24-8.5 Metal Splice Tray, 24 Position Fusion Splice Chip, 8.5”L x 5.06”W x .42”H $18.95 F1-SPL24XL Aluminum Splice Tray, 24 Position, XL, Fusion Splice Chip, Rigid, 10"L x 5"W x 0.41"H $22.95 F1-6707BLKF Metal Splice Tray, 12 Position Fusion Splice Chip, 7.5”L x 4”W x .63”H $14.95 F1-13187 Cable Retention Rings For 1RU & 2RU Interconnect (10 Pack) $6.95 F1-MCMB Metal Cable Management Spools (Pair) $16.75
8 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide 2RU Rack Mount Enclosure FIS Fiber Optic Enclosure Product Line The 2RU FIS Rack Mount Enclosure provides many flexible configurations in a 2RU form factor. It accommodates either (4) or (6) LGX adapter plates, modules or cassettes depending on the model chosen. Slide out trays and removable front and back doors allow easy access to the patch bay. Multiple cable retention brackets and tie down spots allow for convenient cable management. Spring loaded stop latches keep the tray securely in place when retracted. Rack mount installs into a standard 19” rack. Adapter plates, 23” mounting brackets and 19” flush mounting brackets are sold separately. • Slide Out Tray with Spring Loaded Stop Latch • Holds (4) or (6) LGX Adapter Plates, Cassettes, or Modules • Multiple Tie Downs and Cable Retention Brackets • Hinged Front and Rear Removable Doors • Rugged 14 Gauge Aluminum, Available in Black or Off-White (BW) • Available with solid or lexan door • Order Preloaded with Terminated Cables, Adapters, Pigtails, Splice Trays or Cassettes FEATURES Dimensions (in) 17”W x 14” D x 3.5”H Capacity - 4 Plates Up to 24 (6 Pack) or 32 (8 Pack) Simplex Connections Up to 48 (6 Pack) Duplex Connections (LC or SC) Capacity - 6 Plates Up to 36 (6 Pack) or 48 (8 Pack) Simplex Connections Up to 72 (6 Pack) Duplex Connections (LC or SC) Material .060” Aluminum Coating Electro-statically Applied Powder Coat Available in Black or Off White PART# DESCRIPTION PRICE F1-RM2RU4X 2RU Rack Mount, 4 Plate Capacity, Solid Front/Rear Doors, Black $158.00 F1-RM2RU4XL 2RU Rack Mount, 4 Plate Capacity, Smoked Lexan Front and Solid Rear Door, Black $163.00 F1-RM2RU4X-BW 2RU Rack Mount, 4 Plate Capacity, Solid Front/Rear Doors, Off White $158.00 F1-RM2RU4XL-BW 2RU Rack Mount, 4 Plate Capacity, Smoked Lexan Front and Solid Rear Door, Off White $163.00 F1RM2RU6X 2RU Rack Mount, 6 Plate Capacity, Solid Front/Rear Doors, Black $163.00 F1RM2RU6XL 2RU Rack Mount, 6 Plate Capacity, Smoked Lexan Front and Solid Rear Door, Black $168.00 F1RM2RU6X-BW 2RU Rack Mount, 6 Plate Capacity, Solid Front/Rear Doors, Off White $163.00 F1RM2RU6XL-BW 2RU Rack Mount, 6 Plate Capacity, Smoked Lexan Front and Solid Rear Door, Off White $168.00 RACK-ADP23 1RU and 2RU 23” Rack Mounting Brackets, Pair, Black $14.95 RACK-ADP23BW 1RU and 2RU 23” Rack Mounting Brackets, Pair, Off White $14.95 F1-SPL12 Metal Splice Tray, 12 Position Fusion Splice Chip, 6.5”L x 4.7”W x .42”H $17.95 F1-SPL24 Metal Splice Tray, 24 Position Fusion Splice Chip, 11.72”L x 3.99”W x .42”H $18.95 F1-SPL24-8.5 Metal Splice Tray, 24 Position Fusion Splice Chip, 8.5”L x 5.06”W x .42”H $18.95 F1-SPL24XL Aluminum Splice Tray, 24 Position, XL, Fusion Splice Chip, Rigid, 10"L x 5"W x 0.41"H $22.95 F1-6707BLKF Metal Splice Tray, 12 Position Fusion Splice Chip, 7.5”L x 4”W x .63”H $14.95 F1-RM2RU4X F1-RM2RU6X
9 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide 4RU Rack Mount Enclosure FIS Fiber Optic Enclosure Product Line The 4RU FIS Rack Mount Enclosure provides many flexible configurations in a 4RU form factor. It accommodates either (12) LGX adapter plates, modules or cassettes. Slide out trays and removable front and back doors allow easy access to the patch bay. Multiple cable retention brackets and tie down spots allow for convenient cable management. Spring loaded stop latches keep the tray securely in place when retracted. Rack mount installs into a standard 19” rack. Adapter plates, 23” mounting brackets and 19” flush mounting brackets are sold separately. Dimensions (in) 17”W x 14” D x 3.5”H Capacity Up to 72 (6 Pack) or 96 (8 Pack) Simplex Connections Up to 144 (6 Pack) Duplex Connections (LC or SC) Material .060” Aluminum Coating Electro-statically Applied Powder Coat Available in Black or Off White PART# DESCRIPTION PRICE F1RM4RU12X 4RU Rack Mount, 12 Plate Capacity, Solid Front/Rear Doors, Black $196.00 F1RM4RU12XL 4RU Rack Mount, 12 Plate Capacity, Smoked Lexan Front and Solid Rear Door, Black $200.00 F1RM4RU12X-BW 4RU Rack Mount, 12 Plate Capacity, Solid Front/Rear Doors, Off White $196.00 F1RM4RU12XL-BW 4RU Rack Mount, 12 Plate Capacity, Smoked Lexan Front and Solid Rear Door, Off White $200.00 4RURACK-ADP23 4RU and 8RU 23” Rack Mounting Brackets, Pair, Black $14.95 4RURACK-ADP23BW 4RU and 8RU 23” Rack Mounting Brackets, Pair, Off White $14.95 F1-SPL12 Metal Splice Tray, 12 Position Fusion Splice Chip, 6.5”L x 4.7”W x .42”H $17.95 F1-SPL24 Metal Splice Tray, 24 Position Fusion Splice Chip, 11.72”L x 3.99”W x .42”H $18.95 F1-SPL24-8.5 Metal Splice Tray, 24 Position Fusion Splice Chip, 8.5”L x 5.06”W x .42”H $18.95 F1-SPL24XL Aluminum Splice Tray, 24 Position, XL, Fusion Splice Chip, Rigid, 10"L x 5"W x 0.41"H $22.95 F1-6707BLKF Metal Splice Tray, 12 Position Fusion Splice Chip, 7.5”L x 4”W x .63”H $14.95 F1-RM4RU12XL Shown with SC/APC Adapters • Slide Out Tray with Spring Loaded Stop Latch • Holds (12) LGX Adapter Plates, Cassettes, or Modules • Built In Raised Splice Tray Mounting Bracket • Multiple Tie Downs and Cable Retention Brackets • Hinged Front and Rear Removable Doors, Lexan Doors Available • Rugged 14 Gauge Aluminum, Available in Black or Off-White (BW) • Order Preloaded with Terminated Cables, Adapters, Pigtails, Splice Trays or Cassettes FEATURES
10 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide 8RU Rack Mount Enclosure FIS Fiber Optic Enclosure Product Line The 8RU FIS Rack Mount Enclosure provides many flexible configurations in an 8RU form factor. It accommodates either (24) LGX adapter plates, modules or cassettes. Slide out trays and removable front and back doors allow easy access to the patch bay. Multiple cable retention brackets and tie down spots allow for convenient cable management. Spring loaded stop latches keep the tray securely in place when retracted. Rack mount installs into a standard 19” rack. Adapter plates, 23” mounting brackets and 19” flush mounting brackets are sold separately. • (2) Slide Out Trays with Spring Loaded Stop Latch • Holds (24) LGX Adapter Plates, Cassettes, or Modules • Built In Raised Splice Tray Mounting Bracket • Multiple Tie Downs and Cable Retention Brackets • Hinged Front and Rear Removable Doors, Lexan Doors Available • Rugged 14 Gauge Aluminum, Available in Black or Off-White (BW) • Order Preloaded with Terminated Cables, Adapters, Pigtails, Splice Trays or Cassettes FEATURES Dimensions (in) 17”W x 14” D x 14”H Capacity Up to 144 (6 Pack) or 192 (8 Pack) Simplex Connections Up to 288 (6 Pack) Duplex Connections (LC or SC) Material .060” Aluminum Coating Electro-statically Applied Powder Coat Available in Black or Off White PART# DESCRIPTION PRICE F1RM8RU24X 8RU Rack Mount, 24 Plate Capacity, Solid Front/Rear Doors, Black $294.00 F1RM8RU24XL 8RU Rack Mount, 24 Plate Capacity, Smoked Lexan Front and Solid Rear Door, Black $298.00 F1RM8RU24X-BW 8RU Rack Mount, 24 Plate Capacity, Solid Front/Rear Doors, Off White $294.00 F1RM8RU24XL-BW 8RU Rack Mount, 24 Plate Capacity, Smoked Lexan Front and Solid Rear Door, Off White $298.00 4RURACK-ADP23 4RU and 8RU 23” Rack Mounting Brackets, Pair, Black $14.95 4RURACK-ADP23BW 4RU and 8RU 23” Rack Mounting Brackets, Pair, Off White $14.95 F1-SPL12 Metal Splice Tray, 12 Position Fusion Splice Chip, 6.5”L x 4.7”W x .42”H $17.95 F1-SPL24 Metal Splice Tray, 24 Position Fusion Splice Chip, 11.72”L x 3.99”W x .42”H $18.95 F1-SPL24-8.5 Metal Splice Tray, 24 Position Fusion Splice Chip, 8.5”L x 5.06”W x .42”H $18.95 F1-SPL24XL Aluminum Splice Tray, 24 Position, XL, Fusion Splice Chip, Rigid, 10"L x 5"W x 0.41"H $22.95 F1-6707BLKF Metal Splice Tray, 12 Position Fusion Splice Chip, 7.5”L x 4”W x .63”H $14.95 F1-RM8RU24XL Shown with SC/APC Adapters
11 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line 1RU Slack Cable Management Enclosure The FIS 1RU Slack Cable Management Enclosure provides a secure, dedicated space for fiber optic cable slack storage. The slide out tray and removable doors provide easy access when managing fiber. The enclosure includes (4) management pucks and multiple tie down positions located near cable entry and exit holes. Comfortably route and store up to 25 meters of 3.0mm simplex fiber around the semicircular slack management rings. The pre-installed slack management rings are 1” high and feature a 3.5 cm cable bend radius. Spring loaded stop latches keep the tray securely in place when retracted. The rack mount enclosure installs into a standard 19” telco rack. If needed, 23” mounting brackets and 19” flush mounting brackets are sold separately. Constructed from durable 14 gauge aluminum and powder coated black, this enclosure is also lightweight and rugged. • Store up to 25 Meters of 3.0mm Simplex Fiber • Slide Out Tray with Spring Loaded Stop Latch • Multiple Tie Downs and Cable Retention Brackets • Hinged Front and Rear Removable Doors • Rugged 14 Gauge Aluminum, Black FEATURES Dimensions 17”W x 14”D x 1.75”H Fiber Capacity Up to 25 Meters of 3.00mm Simplex Fiber Material .060” Aluminum Coating & Color Electro-statically Applied Powder Coat, Black PART# DESCRIPTION PRICE F1RM1RUSCM 1 RU Slack Cable Management Enclosure $133.00 Part #: F1RM1RUSCM
12 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line 1RU High Density Breakout Cassette Enclosure The High Density Breakout Cassette, 1RU Enclosure provides a high density ‘plug and play’ solution within data center infrastructure. It offers a secure breakout point from multi-fiber MPO trunk cables to duplex LC patch cables. This modular platform provides a convenient, rapid deployment solution when installing MPO trunk cables and breakout positions within a network. Install up to (3) HD Breakout Cassettes for a total of 144 fibers loaded in the 1RU enclosure. The enclosure is designed to fit into standard 19” racks. Mounting adapter brackets extend out past the front and back of the enclosure to assist with incoming fiber management. A fiber lacing bar is also included along the back of the enclosure to route fibers. Both front and rear shields are easily removable and provide uninhibited access to the cassette’s fiber connections. Dimensions (with mounting brackets) 17.00” L x 18” W x 1.70”H Capacity (3) HD Breakout Cassettes Material .095” C.R. Steel & .064” Aluminum Coating & Color Electro Statically Applied Powder Coat, Beige Rack Size 19” Telco Rack Weight (Empty) 4.0 lbs • Compact, Cassette Based Enclosure • 1RU Enclosure Accepts (3) HD Breakout Cassettes • Up to 144 Fibers in a 1RU Enclosure FEATURES • Variety of HD Breakout Cassette Configurations • Enclosure Accommodates Standard 19” Rack • Manufactured in USA PART# DESCRIPTION PRICE F1RM1RU3XHD 1RU High Density Breakout Cassette Enclosure, Empty, Holds (3) HD Breakout Cassettes $132.00 F1HDMTP48OM3MT12ELA HD Breakout Cassette, 48 Fiber, OM3, (24) Duplex LC/PC Aqua to (4) 12F Elite MPO/Male, Polarity Type A $470.00 F1HDMTP48OM4MT12ELA HD Breakout Cassette, 48 Fiber, OM4, (24) Duplex LC/PC Magenta to (4) 12F Elite MPO/Male, Polarity Type A $472.50 F1HDMTP48OS2MT12ELUA HD Breakout Cassette, 48 Fiber, SM, (24) Duplex LC/UPC Blue to (4) 12F Elite MPO/Male, Polarity Type A $532.50 F1HDMTP48OS2MT12ELAA HD Breakout Cassette, 48 Fiber, SM, (24) Duplex LC/APC Green to (4) 12F Elite MPO/Male, Polarity Type A $550.00 F1HDMTP48OM3MT12ELB HD Breakout Cassette, 48 Fiber, OM3, (24) Duplex LC/PC Aqua to (4) 12F Elite MPO/Male, Polarity Type B $470.00 F1HDMTP48OM4MT12ELB HD Breakout Cassette, 48 Fiber, OM4, (24) Duplex LC/PC Magenta to (4) 12F Elite MPO/Male, Polarity Type B $472.50 Part #: F1-RM1RU3XHD Shown with (3) HD Cassettes Installed Front & Rear Shields Not Pictured
13 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line High Density Breakout Cassette The High Density Breakout Cassette is designed to reduce installation time and increase cost efficiency within dense network infrastructures. This compact, modular solution provides a convenient solution when transitioning between duplex LC patch cables and multi-fiber MPO trunk cables. Install up to three HD Breakout Cassettes in the compatible 1RU High Density Cassette Enclosure (p/n F1RM1RUHDMPOLC) for a maximum of 144 fibers in a 1RU enclosure. Use in conjunction with pre-terminated cable assemblies for easy installation and simplified cable management. Cassettes are available in a variety of fiber configurations and polarities (Type A and B). Removable ‘fiber ID’ cards and labeled ports are used to identify the internal LC-MPO fiber breakout after cassette installation is complete. The High Density Breakout Cassette is manufactured in the USA with the highest grade optical components. Each cassette is factory tested to provide the best network reliability and optical performance available. • 48 Fiber LC to MPO Breakout Cassette • ‘Plug and Play’ Solution • Variety of Configurations Available • Tool-Less Cassette Installation • Elite Optical Performance • Manufactured in the USA FEATURES F1HDMTP48OS2MT12ELUA Fiber Type MM OM3 50/125μm MM OM4 50/125μm SM OS2 9/125μm SM OS2 9/125μm Fiber Count 48 Fiber 48 Fiber 48 Fiber 48 Fiber Front Connector Type (24) Duplex LC/PC, Female (24) Duplex LC/PC, Female (24) Duplex LC/UPC, Female (24) Duplex LC/APC, Female Rear Connector Type (4) 12F Elite MPO, Male (4) 12F Elite MPO, Male (4) 12F Elite MPO, Male (4) 12F Elite MPO, Male MPO Polarity Polarity Type A = Key Up to Key Down Polarity Type B = Key Up to Key Up Insertion Loss LC/PC ≤ 0.2dB MPO ≤ 0.35dB LC/PC ≤ 0.2dB MPO ≤ 0.35dB LC/PC ≤ 0.2dB MPO ≤ 0.35dB LC/PC ≤ 0.2dB MPO ≤ 0.35dB Optical Return Loss LC/PC ≤ 25dB MPO ≤ 20dB LC/PC ≤ 25dB MPO ≤ 20dB LC/PC ≤ 50dB MPO ≤ 60dB LC/PC ≤ 55dB MPO ≤ 60dB FIBER SPECIFICATIONS
14 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line Dimensions 9.0” L x 4.8” W x 1.4”H Material .064” Aluminum Coating Electro Statically Applied Powder Coat Weight 1.2 lbs CASSETTE SPECIFICATIONS PART# DESCRIPTION PRICE F1HDMTP48OM3MT12ELA HD Breakout Cassette, 48 Fiber, OM3, (24) Duplex LC/PC Aqua to (4) 12F Elite MPO/Male, Polarity Type A $503.75 F1HDMTP48OM4MT12ELA HD Breakout Cassette, 48 Fiber, OM4, (24) Duplex LC/PC Magenta to (4) 12F Elite MPO/Male, Polarity Type A $503.75 F1HDMTP48OS2MT12ELAA HD Breakout Cassette, 48 Fiber, SM, (24) Duplex LC/APC Green to (4) 12F Elite MPO/Male, Polarity Type A $600.00 F1HDMTP48OS2MT12ELUA HD Breakout Cassette, 48 Fiber, SM, (24) Duplex LC/UPC Blue to (4) 12F Elite MPO/Male, Polarity Type A $550.00 F1HDMTP48OM3MT12ELB HD Breakout Cassette, 48 Fiber, OM3, (24) Duplex LC/PC Aqua to (4) 12F Elite MPO/Male, Polarity Type B $503.75 F1HDMTP48OM4MT12ELB HD Breakout Cassette, 48 Fiber, OM4, (24) Duplex LC/PC Magenta to (4) 12F Elite MPO/Male, Polarity Type B $503.75
15 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line 1RU High Density Rack Mount Enclosure The 1RU 4X Slim High Density Enclosure provides a high density ‘plug and play’ solution within data center infrastructure. It accommodates (4) 4X SHD Plates, Modules or Cassettes. Use with 4X SHD Breakout Cassettes to create a secure breakout point from multifiber MPO trunk cables to duplex LC patch cables. This modular platform provides a convenient, rapid deployment solution when installing MPO trunk cables and breakout positions within a network. The 1RU enclosure is designed to fit into standard 19” telco racks. Mounting adapter brackets extend out past the front and back of the enclosure to assist with fiber management and routing. Both front and rear doors are easily removable and provide uninhibited access to the fiber connections. • Holds (4) 4X SHD Plates, Modules or Cassettes • Accomodates up to 24 Fibers • Mounting Ears Feature Integrated Cable Management • Compatible with Standard 19” Telco Rack • Manufactured in USA FEATURES Dimensions (with mounting brackets) 17.18” L x 16.12” W x 1.72”H Capacity (4) 4X SHD Adapter Plates, Modules or Cassettes Material .095” C.R. Steel & .064” Aluminum Coating & Color Electro Statically Applied Powder Coat, Black Rack Size 19” Telco Rack PART# DESCRIPTION PRICE F1RM1RU4XHD 1 RU Rack Mount, 4X SHD Cassette Enclosure, Unloaded, Black $130.00 F1FM4XHDBKT Flush Mount Bracket Pair Accessory $19.00 F1RM1RU4XHD
16 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line 4X SHD Breakout Cassette The 4X SHD Breakout Cassette is designed to reduce installation time and increase cost efficiency within dense network infrastructures. This compact, modular solution provides a convenient solution when transitioning between duplex LC patch cables and multi-fiber MPO trunk cables. Install up to four 4X SHD Breakout Cassettes in the compatible 1RU 4X SHD Enclosure for a maximum of 96 fibers in a 1RU enclosure. Cassettes are available in a variety of fiber configurations and polarities. Port ID labels identify the internal LC-MPO fiber breakout for installation reference. Each cassette is manufactured in the USA with the highest grade optical components and is factory tested to provide the best network reliability and optical performance available. Configuration Shown: 24F LC/UPC TO (X2) 12F MTP Male/Elite • 24 Fiber LC to MPO Breakout Cassette • ‘Plug and Play’ Solution • Variety of Configurations Available • Tool-Less Cassette Installation • Elite Optical Performance • Manufactured in the USA FEATURES Fiber Type MM OM3 50/125μm MM OM4 50/125μm SM OS2 9/125μm SM OS2 9/125μm Fiber Count 24 Fiber 24 Fiber 24 Fiber 24 Fiber Front Connector Type (12) Duplex LC/PC, Female (12) Duplex LC/PC, Female (12) Duplex LC/UPC, Female (12) Duplex LC/APC, Female Rear Connector Type (2) 12F Elite MPO, Male or (1) 24F Elite MPO, Male (2) 12F Elite MPO, Male or (1) 24F Elite MPO, Male (2) 12F Elite MPO, Male or (1) 24F Elite MPO, Male (2) 12F Elite MPO, Male or (1) 24F Elite MPO, Male MPO Polarity Polarity Type A = Key Up to Key Down Polarity Type B = Key Up to Key Up Insertion Loss LC/PC ≤ 0.2dB MPO ≤ 0.35dB LC/PC ≤ 0.2dB MPO ≤ 0.35dB LC/PC ≤ 0.2dB MPO ≤ 0.35dB LC/PC ≤ 0.2dB MPO ≤ 0.35dB Optical Return Loss LC/PC ≤ 25dB MPO ≤ 20dB LC/PC ≤ 25dB MPO ≤ 20dB LC/PC ≤ 50dB MPO ≤ 60dB LC/PC ≤ 55dB MPO ≤ 60dB FIBER SPECIFICATIONS
17 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line Dimensions 8.85” L x 4.33” W x 1.4”H Material .064” Aluminum Coating Electro Statically Applied Powder Coat Weight 0.7 lbs CASSETTE SPECIFICATIONS PART# DESCRIPTION PRICE F1SHD24OS2MT24ELUA 4X SHD Cassette, 24 Fiber, SM, (12) Duplex LC/UPC to (1) 24F MPO Male, Type A $253.00 F1SHD24OS2MT12ELUA 4X SHD Cassette, 24 Fiber, SM, (12) Duplex LC/UPC to (2) 12F MPO Male, Type A $259.50 F1SHD24OM3/4MT24ELUB 4X SHD Cassette, 24 Fiber, OM3, (12) Duplex LC/UPC to (1) 24F MPO Male, Type B $186.00 F1SHD24OM3/4MT12ELUB 4X SHD Cassette, 24 Fiber, OM3, (12) Duplex LC/UPC to (2) 12F MPO Male, Type B $283.50 F1SHDMPO6A MTP 6 Pack, 4X SHD Adapter Plate, Black Type A $55.00 F1SHDMPO12A MTP 12 Pack, 4X SHD Adapter Plate, Black Type A $86.95 F1SHDBLANK 4X SHD Blank Adapter Plate, Unloaded, No Holes $4.85
18 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Intelligent Transportation System (ITS) Cabinet Enclosure The FIS Intelligent Transportation System (ITS) Cabinet Enclosures come in 2, 4, & 6RU footprints. These flush mount, rack mountable enclosures are specifically geared for ITS (Intelligent Transportation Systems) roadside cabinets, or Computer Room enclosed type cabinets, where the 19” equipment mounting rail, is too close to the door for any protrusion. Key features include the reversible cable manager and rear exit, a fully removable lid and a fixed adapter plate and tray which allows storage space for excess cable. These features make a perfect solution for installing a pre-terminated outside plant trunk cable. Enclosures are available in black upon request. It accommodates FIS extended adapter plates.* It’s recommended to have enclosures loaded with preterminated trunk cables at FIS prior to shipping. Ask your sales representative for more information. *Extended footprint is 6.12”(L) x 1.37”(W) • Fixed Adapter Plate Mounting Bracket • Reversible Cable Management Bracket • Removable Lid • Corning Fan-out Kit Strain Relief Bracket • Gap for Storing Excess Cordage • Mounts to stardand 19” Racks FEATURES Capacity 2RU - 4 Plates | 4RU - 8 Plates | 6RU - 12 Plates Material .060” Aluminum Coatings Electro-statically Applied Powder Coat, Available in Off White F119IN2RUFMWEOG1O Product Buyers Guide FIS Fiber Optic Enclosure Product Line PART# DESCRIPTION DIMENSIONS PRICE F119IN2RUFMWEOG1O 19” Flush Mount 2RU Rack Mount, Extended Footprint,48/96 (LC) fibers, Beige 18.20” x 10.67” x 3.5” $170.00 F119IN4RUFMWEOG1O 19” Flush Mount 4RU Rack Mount, Extended Footprint, 96/192 (LC) fibers,Beige 18.20” x 10.67” x 7” $215.00 F119IN2RUFMWE 19” Flush Mount 2RU Rack Mount, Extended Footprint,48/96 (LC) fibers, Beige 18.20” x 15” x 3.5” $170.00 F119IN4RUFMWE 19” Flush Mount 4RU Rack Mount, Extended Footprint, 96/192 (LC) fibers,Beige 18.20” x 15” x 7” $215.00 F119IN6RUFMWE 19” Flush Mount 6RU Rack Mount, Extended Footprint, 144/288 (LC) fibers, Beige 18.20” x 15” x 10.5” $255.00 PART# DESCRIPTION DIMENSIONS PRICE F1SC6SULE SC/UPC SM 6 Fiber Extended Adapter Plate- Beige 6.12” x 1.37” (L x H) $13.25 F1SC6DSULE SC/UPC SM 12 Fiber Extended Adapter Plate-Beige 6.12” x 1.37” (L x H) $18.25 F1LC6DSULE LC/UPC SM 12 Fiber Extended Adapter Plate- Beige 6.12” x 1.37” (L x H) $16.50 F1LC12DSULE LC/UPC SM 24 Fiber Extended Adapter Plate-Beige 6.12” x 1.37” (L x H) $23.50 F1ST6LSULE ST/UPC SM 6 Fiber Extended Adapter Plate- Beige 6.12” x 1.37” (L x H) $16.50 F1ST12ULE ST/UPC SM 12 Fiber Extended Adapter Plate- Beige 6.12” x 1.37” (L x H) $26.50 F1BLANKUE Blank Plate with No Holes (Unloaded) 6.12” x 1.37” (L x H) $6.50
19 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line Compact Wall Mount, 1 Adapter Plate The FIS Compact Wall Mount has capacity for (1) LGX style adapter plate, Patch & Splice cassette or MPO/MTP cassette. The compact form factor along with an included Din Rail mount allows the enclosure to be mounted virtually anywhere. Equipped with a fully removable door makes either splicing pigtails or patching preterminated cables simple. *40mm splice sleeves (F1100240C-50) are recommended for use in these enclosures. • Hinged, removable door • Holds (1) LGX adapter plate • 2 Din Rail Mounting Positions (Kit Included) • Top and Bottom Cable Entries • Cable management accessories included FEATURES Dimension 7,49”W x 5.5H x 1.69”D Capacity 1 LGX Adapter Plate Material .060” Aluminum Coating Electro Statically Applied Powder Coat; Available in Black PART# DESCRIPTION PRICE F1-CW1X FIS Compact Wall Mount, 1 Adapter Plates, Black $57.95
20 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line Compact Wall Mount, 2 Adapter Plate The FIS Compact Wall Mount has capacity for (2) LGX style adapter plate, Patch & Splice cassette or MPO/MTP cassette. The compact form factor along with an included Din Rail mount allows the enclosure to be mounted virtually anywhere. Equipped with a fully removable door makes either splicing pigtails or patching preterminated cables simple. *40mm splice sleeves (F1100240C-50) are recommended for use in these enclosures. • Hinged, removable door • Holds (2) LGX adapter plate • 2 Din Rail Mounting Positions (Kit Included) • Top and Bottom Cable Entries • Cable management accessories included FEATURES Dimension 7,49”W x 5.5H x 2.57”D Capacity 2 LGX Adapter Plate Material .060” Aluminum Coating Electro Statically Applied Powder Coat; Available in Black PART# DESCRIPTION PRICE F1-CW2X FIS Compact Wall Mount, 2 Adapter Plates, Black $67.95
21 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line Zone Electrical Box Outlet Enclosure The FIS Zone Electrical Box Outlet Enclosure attaches directly to a single gang electrical box that may be at the end of a cable pathway. A single-panel box designed to protect and house small fiber counts for patching from zone trunk cables to individual locations. Ideal for Fiber to the Desk (FTTD) and other LAN, PON, and in-building applications. • Wall Mountable • In-Building Applications • Accepts LGX Adapter Plates FEATURES PART# DESCRIPTION PRICE F1CW1XZONE FIS Zone Single Gang Electrical Box Outlet Enclosure $57.95 Dimensions (HxWxD) 5.5” x 7.5” x 1.35” Material .060” Aluminum Coating Electro Statically Applied Powder Coat; Black F1CW1XZONE
22 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line Mini Wall Mount Enclosure The FIS Mini Wall Mount Patch Panel has capacity for (1) or (2) LGX style adapter plates. Ideal for patching smaller quantities of fibers in a compact form factor. Fiber enters and exits from the bottom of the closure, and a cable spool and tie down bridge stance provides fiber management options. A single door is removable and lockable with a padlock (sold separately). • Patching Capability • Holds (1) or (2) LGX Adapter Plates • Integrated Cable Management Rings • Open Bottom for Cable Entry and Patch Cable Exit • Removable Dual Hinged Door, Padlock Optional • Rugged 14 Gauge Aluminum, Black FEATURES Dimensions 6.38”W x 9.18H x 2.65”D Capacity 1 or 2 LGX Adapter Plates Material .060” Aluminum Coating Electro Statically Applied Powder Coat Available in Black or Off-White PART# DESCRIPTION PRICE F1-MW1X FIS Mini Wall Mount, 1 Adapter Plate Capacity, Black $58.00 F1-MW1X-BW FIS Mini Wall Mount, 1 Adapter Plate Capacity, Off-White $58.00 F1-MW2X FIS Mini Wall Mount, 2 Adapter Plate Capacity, Black $70.00 F1-MW2X-BW FIS Mini Wall Mount, 2 Adapter Plate Capacity, Off-White $70.00 F1-MW1X Shown loaded with connectors, pigtail and SC/APC Adapters
23 Fiber Instrument Sales, Inc. 161 Clear Road Oriskany NY, 13424 1-800-5000-FIS(347) www.fiberinstrumentsales.com ©2024 Fiber Instrument Sales, Inc. All rights reserved. 10/2024 Product Buyers Guide FIS Fiber Optic Enclosure Product Line Economy Wall Mount Enclosure The FIS Economy Wall Mount Patch Panel has capacity for (2) or (4) LGX style adapter plates depending on the model chosen. It features a cable spool, bridge stances and a mounting stud and nut to secure splice trays. The lockable inner door provides safe storage of incoming cable while allowing the technician to manipulate outgoing fiber patches. The outer door is removable and lockable with a padlock (sold separately). The enclosure accommodates up to (2) splice trays with recommended dimensions of 8.5”L x 5”W x 0.5”H or smaller. Ask an FIS sales associate about pre-loading the enclosure with fiber pigtails, splice trays and adapter plates. Manufactured in the USA from rugged 14 gauge aluminum, and finished with a standard black or off-white powder coat. Dimensions F1-EW2X : 12.12” W x 10.33” H x 3.81” D F1-EW4X : 12.12” W x 12.24” H x 3.81” D Capacity (LGX Plates/Cassettes) F1-EW2X : 2 F1-EW4X : 4 Capacity (Splice Trays) F1-EW2X : 2 F1-EW4X : 2 Material .060” Aluminum Coating Electro Statically Applied Powder Coat; Available in Black or Off-White Weight F1-EW2X : 3.75 lbs F1-EW4X : 4.25 lbs F1-EW2X • Splicing and Patching Capability • Holds (2) or (4) LGX Adapter Plates • Holds (2) Splice Trays • Hinged Outer Door, Internal Lockable Door FEATURES • Top and Bottom Entry Holes with Dust Proof Grommets • Cable Management Rings Included • Rugged 14 Gauge Aluminum, Off-White (BW) or Black • Order Preloaded with Adapters, Splice Trays and/or Pigtails PART# DESCRIPTION PRICE F1-EW2X Economy Wall Mount, 2 Adapter Plate Capacity, Black Powder Coat $126.00 F1-EW2X-BW Economy Wall Mount, 2 Adapter Plate Capacity, Off-White Powder Coat $126.00 F1-EW4X Economy Wall Mount, 4 Adapter Plate Capacity, Black Powder Coat $130.00 F1-EW4X-BW Economy Wall Mount, 4 Adapter Plate Capacity, Off-White Powder Coat $130.00 F1-SPL12 Metal Splice Tray, 12 Position Fusion Splice Chip, 6.5”L x 4.7”W x .42”H $17.95 F1-SPL12MINI Aluminum Splice Tray, 12 Position, Fusion Splice Chip, Rigid, 4"L x 4"W x .42"H $14.95
