FIBER INSTRUMENT SALES, INC. • PRODUCT CATALOG 2025-2026 49th Edition PROVIDING FIBER OPTIC SOLUTIONS FOR 40 YEARS Desk Reference 2025-2026 FIBER OPTIC PRODUCT CATALOG 49th Edition Sales Representatives Are Waiting For Your Call! Fiber Instrument Sales,Inc. 1-800–5000–FIS(347) COMMUNICATION FIBER OPTICS PURCHASE ONLINE WWW.FIBERINSTRUMENTSALES.COM FOR OUR FULL LINE OF PRODUCT OFFERINGS CABINETS, ENCLOSURES & SPLICE CASES TEST EQUIPMENT & FUSION SPLICERS CONSUMABLES & CONNECTIVITY BULK CABLE AND FIBER ASSEMBLIES
Dear Customer, Without question, we all wish that a “Golden Age” becomes the future of our country. Technology is the driving force and Fiber Optics are a major part of that technology. Our participation and desire to succeed is crucial to the outcome. The government monies dedicated to “Fiber To The Home” projects and the creation of large “Data Centers” is most likely to maximize U.S. Fiber Optic manufacturing and installation capabilities. The rewarded will be the companies that are willing to wisely invest their resources. Interestingly, sourcing many of our key fiber optic products unique to China presents various challenges. Increased tariffs on China imports will hopefully motivate the U.S. government to clearly define and enforce the clarification of “Made in U.S.A.” products. The existing government guidelines are confusing and many. Presently the transfer of products to neighboring countries to avoid tariffs is difficult to confirm. At Fiber Instrument Sales we expect our customer requirements to significantly increase, creating an exciting 2025-2026. We have a tremendous respect for our partners in business and as always, wish everyone a successful future. With appreciation, Frank Giotto President PRESIDENT’S MESSAGE Manufactured At FIS Drop Cable (Pg 101) Distribution Cable - up to144 Fiber (Pg 98) Splice-On Connectors (Pg 50) Multi Fiber Assemblies (Pg 71) FTTx Fiber Management Center (Pg 80) Network Cabinet (Pg 78) Rack Mount Enclosure (Pg 64) Wall Mount Enclosure (Pg 68) Fan-Out Kits (Pg 103) CABLES CONNECTIVITY ENCLOSURES Armored Cable (Pg 100) Frank Giotto Frank Giotto President and CEO
FIBER INSTRUMENT SALES SALES TEAM · SERVICE · SUPPORT 4 2 3 1 4 2 3 1 3 Region 1 Region 2 Region 4 Region 3 Region 3 & Region 4 Sales Team Region 1 & Region 2 Sales Team SALES TEAM Steve Ermacor Product Line Manager Fiber Interconnects & Strategic Accounts Ext. 2123 sermacor@fissales.com Kirk Donley Senior Vice President Ext. 2104 kdonley@fissales.com Cindy Marino Vice President of Government Sales Ext. 2140 cmarino@fissales.com John Bruno Vice President of Training & Technical Services FIS University Instructor Ext. 2157 jbruno@fissales.com Anthony Russo Vice President of Broadband Solutions PLM FTTx Products Ext. 2173 arusso@fissales.com Robert Licari Product Line Manager Fiber Test Equipment FIS University Instructor Ext.2192 rlicari@fissales.com Steve Casaletta Vice President of Business Development PLM Splicing Products Ext. 2166 scasaletta@fissales.com Ric Lamb Product Line Manager Fiber Fence Ext. 2151 rlamb@fissales.com Jim Fasano FTTx Program Development Ext. 2143 jfasano@fissales.com Trevor Francis Vice President of Sales Strategic Accounts Ext. 2125 tfrancis@fissales.com RENTALS & SERVICES GOVERNMENT SALES WEB SALES Don Shantal Internet Sales Ext. 2170 dshantal@fissales.com Trevor Francis Vice President of Sales Strategic Accounts Ext. 2125 tfrancis@fissales.com INTERNATIONAL Sue Muraca Sr. Account Executive Ext. 2160 smuraca@fissales.com Sally Fenton Sr. Account Executive Ext. 2181 sfenton@fissales.com Trista Piccione Product Line Specialist Fiber Cable Assemblies Sr. Account Executive Ext. 2189 tpiccione@fissales.com Trista Piccione Product Line Specialist Fiber Cable Assemblies Sr. Account Executive Ext. 2189 tpiccione@fissales.com John DeMetro Account Executive Ext. 2131 jdemetro@fissales.com Phil Kamp Account Executive Ext. 2154 pkamp@fissales.com Brandon Schmidt Sr. Sales Representative Ext. 2145 bschmidt@fissales.com Amber Corigliano Sr. Sales Representative Ext. 2103 acorigliano@fissales.com Jennifer Stinger Sr. Account Executive Ext. 2185 jstinger@fissales.com Spencer Hawes Sales Representative Ext. 2152 shawes@fissales.com Sarah McDonald Sales Representative Ext. 2156 smcdonald@fissales.com Calvin Lang Jr. Sr. Sales Representative Ext. 2146 clang@fissales.com Adam Norsen Sr. Sales Representative Ext. 2139 anorsen@fissales.com Nicolas Alexander Sales Representative Ext. 2132 nalexander@fissales.com Kathleen O'Meara Sales Representative Ext. 2126 komeara@fissales.com Autumn Fallon Sales Representative Ext. 2164 afallon@fissales.com AaronWillsey Sales Representative Ext. 4151 awillsey@fissales.com John Russo Rentals & Calibration Manger Ext.2161 jrusso@fissales.com Kayla Angelhow International Sales Manager Ext. 2111 kangelhow@fissales.com Autumn Fallon Sales Representative Ext. 2164 afallon@fissales.com Alicia Aldi Sr. Sales Representative Ext. 2149 aaldi@fissales.com
FIS Offers Products Compliant With the Build America, Buy America Act Over the years, FIS Manufacturing has expanded its offerings, including fiber optic cables with Corning optical fiber, pre-connectorized assemblies, metal enclosures, fiber test equipment, and connectors. With a satisfaction guarantee and ISO9001/2015 certification, FIS ensures top quality. Our products help drive broadband growth across the U.S., many of our products meet Buy America Build America requirements for government-funded projects, including BEAD. CALL FOR CUSTOM QUOTES! 1-800-5000-FIS(347) Fiber Instrument Sales, Inc. is now part of Corning CAH Connections Gold Program! • Required for Corning 25-year extended warranty • Quick turn and shorter lead time • Customized simplex and duplex cable assemblies Contact an FIS Sales Representative Quality, Service, Peace of Mind: Gold Cable Assembler BUILD AMERICA BUY AMERICA COMPLIANT
pg. 75 FIS HELIOUS Outdoor Wall Mount Enclsoure NEW PRODUCTS 2025-2026 pg. 60 FITEL S327A Precision Cleaver pgs. 23 FIS GEMINI Bi-Directional LTS pg. 52 AFL 90S+ Core Alignment Fusion SpliceReady Splicer Kit pg. 27 EXFO FIP-200-A Probe pg. 81 EZfi Drop Cable Assembly System FIS Network Interface Device Box (NID) pg. 82 Corning® OptiSnap™ High-Performance Connector Toolkit with Flat Cleaver pg. 130 pg. 22 FIS FIS xWDM Channel Analyzers pg. 116 FIS Fiber Optic Simplex/Duplex Thermal Stipper pg. 43 AFL FlowScout Optical Loss Test Kits pg. 90 AFL APEX X-1 Closures Coming Soon!
Live Tech Help Our sales people and tech support are available by phone as well as online, via our website. You can access our Sales Team, Product Line Managers, Vice Presidents, or President and CEO, Frank Giotto. Just click on the link, “Ask A Question.” We have a Connection! With our Video Conference Room FIS is able to provide training and technical support to our customers with ease. This support includes several different types of equipment such as fusion splicers, OTDRs, connector termination kits, and optical loss test sets and much more. Let us know if you’re interested in setting up a video conference call F I B E R O P T I C S Tutorial Videos Fusion splicing, fiber termination and network testing are just a few of the informative FIS videos available to you. Videos can be accessed through the FISWebsite. Clear and concise, FIS tutorial videos are the next best thing to receiving classroom training. You will love our Configurator Today’s network installations sometimes require customized solutions and here at FIS we are ready to put together a solution that will make your job easier. Do you need to connect a piece of equipment that is further away from the enclosure than a standard length patch cable? Let us build you a custom length patch cable! Our standard turnaround time is 2 to 4 business days. Let’s make your custom solution together! Communicator Newsletter This quarterly publication is a great tool for helping you make informed purchase decisions. For example, various issues of Communicator have provided guidance in selecting the right fusion splicer, OTDR, splice closure and more. Refer to these Communicator “buying guides”when making important purchase decisions. All issues are available in the Communicator Archives on the FIS website. Continuing to be Your Fiber-Optic Information Source Website www.fiberinstrumentsales.com In addition to online shopping, the FIS website offers a wealth of information to make your job easier and more productive. Spec sheets, white papers, training videos, and Communicator Newsletter – all are accessible online. Shop 24/7 Online
TABLE OF CONTENTS Consumables Wipes 104 Cleaning Solutions 105 Dry Cleaners 108 Swabs 110 Cleaning Kits 111 Tools Tool Kits 112 Stripping & Tools 116 Hand Tools 117 Slitting Tools 117 MidAccess Tools 119 Scribes & Crimpers 120 Hand Tools 121 Cable Pulling 123 TieWraps & Accessories 124 Marking and Labeling 125 Tents 127 Innerduct 128 Pulling Eye 128 Cable 250µm / 900µm / Large Core 95 Simplex / Duplex 96, 99 Distribution 98 Indoor/Outdoor 99 Aluminum Interlocking Armor 100 Outdoor 101 Drop Cable 101 Furcation Tube 102 Breakout / Fanout Kits 103 Closures (Outdoor) Home Installation Kit 81 NIDs 82 Outdoor Splice Closures 82-85, 88-91 Drop Cable 83 Couplers/Splitters 86 CWDM/DWDM 87 Vaults & Pedestals 92 Snowshoes 93 Connectivity Splice-On Connectors 50 Quick Termination 129 Standard Connectors 132, 134,135 Small Form Factor Connectors 133 Boots & Accessories 136 Epoxy 138 Connector Ovens 139 Polishing 140 Adapters 144 Attenuators 149 Services Equipment Rentals 166 Calibration 167 Financing 167 Drilled Ferrules 152 FIBER FENCE Security 151 Network Equipment SFPs 157 UBIQUITINetworkEquipment 158 MediaConverters&Switches 160 Hardened Environment Switches 162 Active Fiber Optic & Copper Assemblies 163 Copper Category 5e, 6 / Cable 154 Copper Testing 155 Wall Plates / Jacks 156 Patch Panels 156 FIS University Training Classes 164 Training Material 165 Assemblies Singlemode, ClearCurve© 6 Multimode 10 Gig OM3 / OM4 8 Multimode OM2 / OM1 9 Custom Assemblies 10 MTP Cable Assemblies 12 Mode Conditioning 14 Specialty Optical Assemblies 14 Coupler/Splitter Modules 15 Broadcast/Military & Harsh Environment 16 Splicing Fusion Splicers 50 Splice-On Connectors 50 Cleavers 60 Mechanical Splices 62 Splice Protection Sleeves 63 Enclosures (Indoor) Rack Mount Enclosures 64, 67 Wall Mount Enclosures 66, 68 Custom Enclosures 67,68 Adapter Panels 70 Pigtails / Snap Packs 71 Splice Trays 76 Racks 78 Cable Management 79 ZEUS FTTx Solution 80 Test Equipment OTDRs 20-26,28-34 Fiber Inspection 21, 27, 30, 31, 44, 45 Pulse / Test Boxes 35 Fiber Optic Identifiers 36 Power Meter & Light Sources 38, 39,42, 43 MPO Testing 40 Fault Locators 46 Testing Accessories 48
6 1.800.5000.FIS (347) | fiberinstrumentsales.com | @FISsales | /FISsales ASSEMBLIES | UPC SINGLEMODE - SIMPLEX & DUPLEX PATCH CABLE 3mm ST-ST UPC SIMPLEX PART # LENGTH PRICE S98U8US1FISCU 1 Meter $3.85 S98U8US2FISCU 2 Meters 3.95 S98U8US3FISCU 3 Meters 4.10 S98U8US5FISCU 5 Meters 4.30 S98U8US10FISCU 10 Meters 4.90 3mm SC-SC UPC SIMPLEX PART # LENGTH PRICE S9YUYUS1FISCU 1 Meter $3.85 S9YUYUS2FISCU 2 Meters 3.95 S9YUYUS3FISCU 3 Meters 4.05 S9YUYUS5FISCU 5 Meters 4.30 S9YUYUS10FISCU 10 Meters 4.90 3mm ST-SC UPC SIMPLEX PART # LENGTH PRICE S98UYUS1FISCU 1 Meter $3.85 S98UYUS2FISCU 2 Meters 3.95 S98UYUS3FISCU 3 Meters 4.10 S98UYUS5FISCU 5 Meters 4.30 S98UYUS10FISCU 10 Meters 4.90 1.6mm LC-LC UPC SIMPLEX PART # LENGTH PRICE Y9LULUS1FISCU 1 Meter $4.35 Y9LULUS2FISCU 2 Meters 4.50 Y9LULUS3FISCU 3 Meters 4.60 Y9LULUS5FISCU 5 Meters 4.85 Y9LULUS10FISCU 10 Meters 5.45 1.6mm LC-SC UPC SIMPLEX PART # LENGTH PRICE Y9LUYUS1FISCU 1 Meter $4.10 Y9LUYUS2FISCU 2 Meters 4.20 Y9LUYUS3FISCU 3 Meters 4.35 Y9LUYUS5FISCU 5 Meters 4.60 Y9LUYUS10FISCU 10 Meters 5.20 3mm FC-FC UPC SIMPLEX PART # LENGTH PRICE S97U7US1FISCU 1 Meter $3.85 S97U7US2FISCU 2 Meters 3.95 S97U7US3FISCU 3 Meters 4.10 S97U7US5FISCU 5 Meters 4.30 S97U7US10FISCU 10 Meters 4.90 1.6mm LC-SC UPC DUPLEX PART # LENGTH PRICE X9LUYUS1FISCU 1 Meter $8.15 X9LUYUS2FISCU 2 Meters 8.40 X9LUYUS3FISCU 3 Meters 8.65 X9LUYUS5FISCU 5 Meters 9.15 X9LUYUS10FISCU 10 Meters 10.35 1.6mm LC-LC UPC DUPLEX PART # LENGTH PRICE X9LULUS1FISCU 1 Meter $8.75 X9LULUS2FISCU 2 Meters 8.90 X9LULUS3FISCU 3 Meters 9.20 X9LULUS5FISCU 5 Meters 9.65 X9LULUS10FISCU 10 Meters 10.85 3mm ST-SC UPC DUPLEX PART # LENGTH PRICE D98UYUS1FISCU 1 Meter $7.70 D98UYUS2FISCU 2 Meters 7.95 D98UYUS3FISCU 3 Meters 8.15 D98UYUS5FISCU 5 Meters 8.60 D98UYUS10FISCU 10 Meters 9.80 3mm SC-SC UPC DUPLEX PART # LENGTH PRICE D9YUYUS1FISCU 1 Meter $7.65 D9YUYUS2FISCU 2 Meters 7.95 D9YUYUS3FISCU 3 Meters 8.15 D9YUYUS5FISCU 5 Meters 8.60 D9YUYUS10FISCU 10 Meters 9.80 3mm FC-FC UPC DUPLEX PART # LENGTH PRICE D97U7US1FISCU 1 Meter $7.70 D97U7US2FISCU 2 Meters 7.95 D97U7US3FISCU 3 Meters 8.20 D97U7US5FISCU 5 Meters 8.70 D97U7US10FISCU 10 Meters 9.95 3mm ST-ST UPC DUPLEX PART # LENGTH PRICE D98U8US1FISCU 1 Meter $7.65 D98U8US2FISCU 2 Meters 7.95 D98U8US3FISCU 3 Meters 8.20 D98U8US5FISCU 5 Meters 8.70 D98U8US10FISCU 10 Meters 9.95 1.6mm LC-LC UPC UNI-BOOT DUPLEX PART # LENGTH PRICE X9LULUS1FISCUNI 1 Meter $12.90 X9LULUS2FISCUNI 2 Meters 13.15 X9LULUS3FISCUNI 3 Meters 13.35 X9LULUS5FISCUNI 5 Meters 13.85 X9LULUS10FISCUNI 10 Meters 15.10 CORNING®SMF-28®ULTRA FIBER SM PATCH CABLES ASSEMBLIES
7 /FISsales | @FISsales | fiberinstrumentsales.com | 1.800.5000.FIS (347) ASSEMBLIES | APC SINGLEMODE & CORNING®SMF-28®ULTRA OPTICAL FIBER - SIMPLEX & DUPLEX 1.6mm LC-LC APC SIMPLEX PART # LENGTH PRICE Y9LALAS1FISCU 1 Meter $4.70 Y9LALAS2FISCU 2 Meters 4.85 Y9LALAS3FISCU 3 Meters 4.95 Y9LALAS5FISCU 5 Meters 5.20 Y9LALAS10FISCU 10 Meters 5.80 3mm FC-SC APC DUPLEX PART # LENGTH PRICE D97AYAS1FISCU 1 Meter $8.50 D97AYAS2FISCU 2 Meters 8.80 D97AYAS3FISCU 3 Meters 9.10 D97AYAS5FISCU 5 Meters 9.70 D97AYAS10FISCU 10 Meters 11.15 3mm FC-FC APC SIMPLEX PART # LENGTH PRICE S97A7AS1FISCU 1 Meter $4.25 S97A7AS2FISCU 2 Meters 4.35 S97A7AS3FISCU 3 Meters 4.50 S97A7AS5FISCU 5 Meters 4.75 S97A7AS10FISCU 10 Meters 5.35 3mm SC-SC APC SIMPLEX PART # LENGTH PRICE S9YAYAS1FISCU 1 Meter $4.25 S9YAYAS2FISCU 2 Meters 4.35 S9YAYAS3FISCU 3 Meters 4.50 S9YAYAS5FISCU 5 Meters 4.75 S9YAYAS10FISCU 10 Meters 5.35 1.6mm LC-LC APC DUPLEX PART # LENGTH PRICE X9LALAS1FISCU 1 Meter $9.40 X9LALAS2FISCU 2 Meters 9.65 X9LALAS3FISCU 3 Meters 9.90 X9LALAS5FISCU 5 Meters 10.40 X9LALAS10FISCU 10 Meters 11.65 3mm SC-SC APC DUPLEX PART # LENGTH PRICE D9YAYAS1FISCU 1 Meter $8.45 D9YAYAS2FISCU 2 Meters 8.70 D9YAYAS3FISCU 3 Meters 8.95 D9YAYAS5FISCU 5 Meters 9.45 D9YAYAS10FISCU 10 Meters 10.65 1.6mm SC/APC - LC/UPC SIMPLEX PART # LENGTH PRICE Y9YALUS1FISCU 1 Meter $4.30 Y9YALUS2FISCU 2 Meters 4.40 Y9YALUS3FISCU 3 Meters 4.55 Y9YALUS5FISCU 5 Meters 4.80 Y9YALUS10FISCU 10 Meters 5.40 3mm FC-SC APC SIMPLEX PART # LENGTH PRICE S9YA7AS1FISCU 1 Meter $4.25 S9YA7AS2FISCU 2 Meters 4.35 S9YA7AS3FISCU 3 Meters 4.50 S9YA7AS5FISCU 5 Meters 4.75 S9YA7AS10FISCU 10 Meters 5.35 1.6mm LC-SC APC SIMPLEX PART # LENGTH PRICE Y9YALAS1FISCU 1 Meter $4.50 Y9YALAS2FISCU 2 Meters 4.60 Y9YALAS3FISCU 3 Meters 4.75 Y9YALAS5FISCU 5 Meters 4.95 Y9YALAS10FISCU 10 Meters 5.60 1.6mm LC/APC -SC/UPC DUPLEX PART # LENGTH PRICE X9LAYUS1FISCU 1 Meter $8.50 X9LAYUS2FISCU 2 Meters 8.75 X9LAYUS3FISCU 3 Meters 9.00 X9LAYUS5FISCU 5 Meters 9.50 X9LAYUS10FISCU 10 Meters 10.70 1.6mm LC-LC APC UNI-BOOT DUPLEX PART # LENGTH PRICE X9LALAS1FISCUNI 1 Meter $13.85 X9LALAS2FISCUNI 2 Meters 14.10 X9LALAS3FISCUNI 3 Meters 14.35 X9LALAS5FISCUNI 5 Meters 14.80 X9LALAS10FISCUNI 10 Meters 16.00 CORNING®SMF-28®ULTRA FIBER SM PATCH CABLES
8 1.800.5000.FIS (347) | fiberinstrumentsales.com | @FISsales | /FISsales ASSEMBLIES | 10 GIG MULTIMODE SIMPLEX & DUPLEX PATCH CABLE - 50µm OM3 & OM4 1.6mm SC-SC PC SIMPLEX -50µm OM3 PART # LENGTH PRICE Y8YYM1FISC 1 Meter $3.65 Y8YYM2FISC 2 Meters 4.00 Y8YYM3FISC 3 Meters 4.20 Y8YYM5FISC 5 Meters 5.05 Y8YYM10FISC 10 Meters 6.75 1.6mm LC-LC PC SIMPLEX - 50µm OM3 PART # LENGTH PRICE Y8LLM1FISC 1 Meter $4.15 Y8LLM2FISC 2 Meters 4.85 Y8LLM3FISC 3 Meters 4.85 Y8LLM5FISC 5 Meters 5.50 Y8LLM10FISC 10 Meters 7.25 1.6mm ST-ST PC SIMPLEX -50µm OM3 PART # LENGTH PRICE Y888M1FISC 1 Meter $3.70 Y888M2FISC 2 Meters 4.00 Y888M3FISC 3 Meters 4.35 Y888M5FISC 5 Meters 5.05 Y888M10FISC 10 Meters 6.75 1.6mm LC-SC PC SIMPLEX -50µm OM3 PART # LENGTH PRICE Y8LYM1FISC 1 Meter $3.90 Y8LYM2FISC 2 Meters 4.10 Y8LYM3FISC 3 Meters 4.60 Y8LYM5FISC 5 Meters 5.20 Y8LYM10FISC 10 Meters 7.00 1.6mm SC-ST PC SIMPLEX -50µm OM3 PART # LENGTH PRICE Y8Y8M1FISC 1 Meter $3.70 Y8Y8M2FISC 2 Meters 4.00 Y8Y8M3FISC 3 Meters 4.35 Y8Y8M5FISC 5 Meters 5.05 Y8Y8M10FISC 10 Meters 6.75 1.6mm LC-ST PC SIMPLEX -50µm OM3 PART # LENGTH PRICE Y8L8M1FISC 1 Meter $3.90 Y8L8M2FISC 2 Meters 4.20 Y8L8M3FISC 3 Meters 4.60 Y8L8M5FISC 5 Meters 5.30 Y8L8M10FISC 10 Meters 7.00 1.6mm SC-SC PC DUPLEX -50µm OM3 PART # LENGTH PRICE X8YYM1FISC 1 Meter $6.25 X8YYM2FISC 2 Meters 8.00 X8YYM3FISC 3 Meters 8.70 X8YYM5FISC 5 Meters 10.10 X8YYM10FISC 10 Meters 13.50 1.6mm SC-SC PC DUPLEX -50µm OM4 X10YYM1FISC 1 Meter $7.65 X10YYM2FISC 2 Meters 8.70 X10YYM3FISC 3 Meters 9.70 X10YYM5FISC 5 Meters 11.75 X10YYM10FISC 10 Meters 16.80 1.6mm LC-LC PC DUPLEX -50µm OM3 PART # LENGTH PRICE X8LLM1FISC 1 Meter $8.30 X8LLM2FISC 2 Meters 8.95 X8LLM3FISC 3 Meters 9.65 X8LLM5FISC 5 Meters 11.00 X8LLM10FISC 10 Meters 14.45 1.6mm LC-LC PC DUPLEX -50µm OM4 X10LLM1FISC 1 Meter $8.65 X10LLM2FISC 2 Meters 10.55 X10LLM3FISC 3 Meters 10.65 X10LLM5FISC 5 Meters 12.70 X10LLM10FISC 10 Meters 17.75 1.6mm ST-ST PC DUPLEX -50µm OM3 PART # LENGTH PRICE X888M1FISC 1 Meter $7.35 X888M2FISC 2 Meters 8.00 X888M3FISC 3 Meters 8.70 X888M5FISC 5 Meters 10.10 X888M10FISC 10 Meters 13.50 1.6mm LC-SC PC DUPLEX -50µm OM3 PART # LENGTH PRICE X8LYM1FISC 1 Meter $7.80 X8LYM2FISC 2 Meters 8.50 X8LYM3FISC 3 Meters 9.20 X8LYM5FISC 5 Meters 10.55 X8LYM10FISC 10 Meters 11.25 1.6mm LC-SC PC DUPLEX -50µm OM4 X10LYM1FISC 1 Meter $8.15 X10LYM2FISC 2 Meter 9.15 X10LYM3FISC 3 Meter 10.20 X10LYM5FISC 5 Meter 12.20 X10LYM10FISC 10 Meter 17.30 1.6mm SC-ST PC DUPLEX -50µm OM3 PART # LENGTH PRICE X8Y8M1FISC 1 Meter $7.35 X8Y8M2FISC 2 Meters 8.00 X8Y8M3FISC 3 Meters 8.70 X8Y8M5FISC 5 Meters 10.10 X8Y8M10FISC 10 Meters 13.50 1.6mm LC-ST PC DUPLEX -50µm OM3 PART # LENGTH PRICE X8L8M1FISC 1 Meter $7.80 X8L8M2FISC 2 Meters 8.50 X8L8M3FISC 3 Meters 9.20 X8L8M5FISC 5 Meters 11.35 X8L8M10FISC 10 Meters 13.95
9 /FISsales | @FISsales | fiberinstrumentsales.com | 1.800.5000.FIS (347) CUSTOM LENGTHS AVAILABLE ASSEMBLIES | MULTIMODE SIMPLEX & DUPLEX PATCH CABLE - 50µm & 62.5µm OM1 & OM2 3mm ST-ST DUPLEX - 50µm OM2 PART # LENGTH PRICE D188M1FISC 1 Meter $7.15 D188M2FISC 2 Meters 7.65 D188M3FISC 3 Meters 8.20 D188M5FISC 5 Meters 9.20 D188M10FISC 10 Meters 11.70 3mm ST-ST DUPLEX - 62.5µm OM1 D288M1FISC 1 Meter $7.15 D288M2FISC 2 Meters 8.60 D288M3FISC 3 Meters 8.20 D288M5FISC 5 Meters 9.20 D288M10FISC 10 Meters 12.90 1.6mm LC-LC DUPLEX - 50µm OM2 PART # LENGTH PRICE X1LLM1FISC 1 Meter $8.10 X1LLM2FISC 2 Meters 8.65 X1LLM3FISC 3 Meters 9.15 X1LLM5FISC 5 Meters 10.15 X1LLM10FISC 10 Meters 12.65 1.6mm LC-LC DUPLEX - 62.5µm OM1 X2LLM1FISC 1 Meter $8.10 X2LLM2FISC 2 Meters 8.60 X2LLM3FISC 3 Meters 9.10 X2LLM5FISC 5 Meters 10.15 X2LLM10FISC 10 Meters 12.70 3mm SC-SC DUPLEX - 50µm OM2 PART # LENGTH PRICE D1YYM1FISC 1 Meter $7.20 D1YYM2FISC 2 Meters 7.70 D1YYM3FISC 3 Meters 8.20 D1YYM5FISC 5 Meters 9.20 D1YYM10FISC 10 Meters 11.70 3mm SC-SC DUPLEX - 62.5µm OM1 D2YYM1FISC 1 Meter $7.15 D2YYM2FISC 2 Meters 7.65 D2YYM3FISC 3 Meters 8.20 D2YYM5FISC 5 Meters 9.20 D2YYM10FISC 10 Meters 10.60 QUANTITY PRICING IN STOCK 3mm ST-ST SIMPLEX - 50µm OM2 PART # LENGTH PRICE S188M1FISC 1 Meter $3.60 S188M2FISC 2 Meters 3.85 S188M3FISC 3 Meters 4.10 S188M5FISC 5 Meters 4.65 S188M10FISC 10 Meters 5.90 3mm ST-ST SIMPLEX - 62.5µm OM1 S288M1FISC 1 Meter $3.60 S288M2FISC 2 Meters 3.85 S288M3FISC 3 Meters 4.10 S288M5FISC 5 Meters 4.65 S288M10FISC 10 Meters 5.90 1.6mm LC-LC SIMPLEX - 50µm OM2 PART # LENGTH PRICE Y1LLM1FISC 1 Meter $4.10 Y1LLM2FISC 2 Meters 4.30 Y1LLM3FISC 3 Meters 4.60 Y1LLM5FISC 5 Meters 5.10 Y1LLM10FISC 10 Meters 6.35 1.6mm LC-LC SIMPLEX - 62.5µm OM1 Y2LLM1FISC 1 Meter $4.10 Y2LLM2FISC 2 Meters 4.30 Y2LLM3FISC 3 Meters 4.60 Y2LLM5FISC 5 Meters 5.10 Y2LLM10FISC 10 Meters 6.35 3mm SC-SC SIMPLEX - 50µm OM2 PART # LENGTH PRICE S1YYM1FISC 1 Meter $3.60 S1YYM2FISC 2 Meters 3.85 S1YYM3FISC 3 Meters 4.10 S1YYM5FISC 5 Meters 4.60 S1YYM10FISC 10 Meters 5.90 3mm SC-SC SIMPLEX - 62.5µm OM1 S2YYM1FISC 1 Meter $3.60 S2YYM2FISC 2 Meters 3.85 S2YYM3FISC 3 Meters 4.10 S2YYM5FISC 5 Meters 4.60 S2YYM10FISC 10 Meters 5.90 3mm ST-SC DUPLEX - 50µm OM2 PART # LENGTH PRICE D18YM1FISC 1 Meter $7.20 D18YM2FISC 2 Meters 7.65 D18YM3FISC 3 Meters 8.15 D18YM5FISC 5 Meters 9.20 D18YM10FISC 10 Meters 12.20 3mm ST-SC DUPLEX - 62.5µm OM1 D28YM1FISC 1 Meter $7.15 D28YM2FISC 2 Meters 7.65 D28YM3FISC 3 Meters 8.20 D28YM5FISC 5 Meters 9.20 D28YM10FISC 10 Meters 11.70 1.6mm ST-LC DUPLEX - 50µm OM2 PART # LENGTH PRICE X18LM1FISC 1 Meter $7.05 X18LM2FISC 2 Meters 8.15 X18LM3FISC 3 Meters 8.65 X18LM5FISC 5 Meters 9.70 X18LM10FISC 10 Meters 11.25 1.6mm ST-LC DUPLEX - 62.5µm OM1 X28LM1FISC 1 Meter $7.70 X28LM2FISC 2 Meters 8.20 X28LM3FISC 3 Meters 9.45 X28LM5FISC 5 Meters 9.65 X28LM10FISC 10 Meters 12.20 1.6mm SC-LC DUPLEX - 50µm OM2 PART # LENGTH PRICE X1YLM1FISC 1 Meter $7.65 X1YLM2FISC 2 Meters 7.55 X1YLM3FISC 3 Meters 8.00 X1YLM5FISC 5 Meters 8.95 X1YLM10FISC 10 Meters 12.20 1.6mm SC-LC DUPLEX - 62.5µm OM1 X2YLM1FISC 1 Meter $7.65 X2YLM2FISC 2 Meters 8.20 X2YLM3FISC 3 Meters 8.65 X2YLM5FISC 5 Meters 10.45 X2YLM10FISC 10 Meters 12.20 HYBRID PATCH CABLE 3mm ST-SC SIMPLEX - 62.5µm OM1 PART # LENGTH PRICE S28YM1FISC 1 Meter $3.60 S28YM2FISC 2 Meters 3.85 S28YM3FISC 3 Meters 4.10 S28YM5FISC 5 Meters 4.60 S28YM10FISC 10 Meters 5.90 1.6mm SC-LC SIMPLEX - 62.5µm OM1 PART # LENGTH PRICE Y2YLM1FISC 1 Meter $3.85 Y2YLM2FISC 2 Meters 4.10 Y2YLM3FISC 3 Meters 4.35 Y2YLM5FISC 5 Meters 4.85 Y2YLM10FISC 10 Meters 6.15 1.6mm ST-LC SIMPLEX - 62.5µm OM1 PART # LENGTH PRICE Y28LM1FISC 1 Meter $3.85 Y28LM2FISC 2 Meters 4.10 Y28LM3FISC 3 Meters 4.35 Y28LM5FISC 5 Meters 4.85 Y28LM10FISC 10 Meters 6.15
10 1.800.5000.FIS (347) | fiberinstrumentsales.com | @FISsales | /FISsales MANUFACTURER OF CABLE ASSEMBLIES • WE ARE FLEXIBLE • WE HAVE FAST DELIVERY / HIGH QUALITY • ADDITIONAL SERVICES WE OFFER • Wide Selection of components from leading manufacturers • Ability to build to Engineering specifications or drawings • From a quantity of 1 or 1,000’s FIS can deliver • Cables are ready to ship nationwide and internationally in as little as 2-4 days • 100% inspection and tested to industry standards • ISO 9001-2015 Certified • Over 30 years of cable assembly experience • Termination of Customer Supplied Materials • Engineered drawings of assemblies • Custom packaging, labeling • Experienced engineering team to help design an assembly for any application TESTING INSERTION LOSS RETURN LOSS MULTIMODE = ≤ 0.4 dB (TYPICAL) SINGLEMODE = ≤ 0.3 dB (TYPICAL) PC = ≤ -25dB UPC = ≤ -55dB APC = ≤ -60dB SPECIFICATIONS LENGTH SIMPLEX/DUPLEX MULTIFIBER TOTAL LENGTH = -0/+3” (< 5 MTRS), -0/+10% (> 5 MTRS) TOTAL LENGTH = -0/+3” (< 5 MTRS), -0/+10% (> 5 MTRS) BREAKOUT = 1 MTR (-0/+3”) MAXIMUM CONNECTOR TO CONNECTOR STAGGER = 1.5” STANDARD CONFIGURATIONS Standard configurations (typical lead-time 2-4 days) – Convert your next project to “plug n’ go”by having your cable assemblies pre-terminated by FIS. Our expert technicians prepare assemblies from a 1-fiber patch cable to 144-fiber assemblies, while offering a wide array of components for you to create the perfect assembly for your application. CUSTOM CONFIGURATIONS Our custom abilities include but are not limited to labeling, packaging, testing requirements, and building to customer supplied specifications and drawings. CUSTOM FIBER OPTIC CABLE FIBER TYPE 3 1=50/125µm - OM2 2=62.5/125µm - OM1 3=8-9/125µm - OS2 4=Other 5=100/140µm 6=200/230µm 7=960/1000µm (plastic) 8=50µm10Gig - OM3 (Bend Insensitive) 9=Singlemode (Ultra-Bend Insensitive) 10=50µm10Gig - OM4 (Bend Insensitive) 12=50µm10Gig - OM5 (Bend Insensitive) USE THIS CHART TO BUILD THE CABLE YOU Choose “RL” For Polarity Reversable LC Note: Choose two connector styles from the chart one for Connector Side A and one for Connector Side B. ARMOR A= Armor See Pages 12 & 13 For MTP Assemblies 1=SMA905 2=SMA906 4=FC/Stainless Alloy 5=ST/Stainless Alloy 7=FC/PC 7A=FC/APC 7U=FC/UPC 8=ST/PC 8A=ST/APC 8U=ST/UPC Y=SC/PC YA=SC/APC YU=SC/UPC D=SC Duplex w/ Clips L=LC/PC LA=LC/APC LU=LC/UPC C=LC Duplex w/ Clips CU=LC Duplex w/Uniboot RL=Polarity Reverse/ Push Pull Boot LC F=Ferrule Only 9A=PM-FC/APC 9U=PM-FC/UPC P=Pigtail AA=High Performance FC/APC (decreases ORL) BA=High Performance SC/APC (decreases ORL) EA=E2000/APC EU=E2000/UPC MJ=MTRJ (no pins) MP=MTRJ (w/pins) MDC = MDC MA = MDC/APC SLA = Short Boot LC/APC SLU = Short Boot LC/UPC SYA = Short Boot SC/APC SYU = Short Boot SC/UPC CONNECTOR SIDE A / SIDE B 7A 8U Largest Manufacturer and Leading Supplier of Cable Assemblies in the USA. CABLE TYPE S GS= GD= E= Corning Gold Simplex Corning Gold Duplex 250umBare Fiber N= 900umBuffered Fiber Z= 1.2mmSimplex Y= 1.6mmSimplex F= 1.8mmSimplex T= 2.0mmSimplex S= 3.0mmSimplex X= 1.6mmDuplex H= 1.8mmDuplex V= 2.0mmDuplex D= 3.0mmDuplex PM= PolarizationMaintaining LZ= LSZH Cable B= Breakout MD= MicroDistribution HD= High DensityMicroDistribution C= Distribution R= Ribbon RF= Ribbon Fan Out TB= Tactical/Broadcast Cable FD= Flat Drop Cable ENC= Epoxy Node Cable IG = Indoor/Outdoor 250um I = Indoor/Outdoor 900um L= LooseTube AER= Aerial
11 /FISsales | @FISsales | fiberinstrumentsales.com | 1.800.5000.FIS (347) CONFIGURATION ILLUSTRATION ASSEMBLY CONFIGURATOR: Part # Example: S-3-7A-8U-S-3-RI-HC-PE Translates to: Simplex 9/125 FC/APC - ST/UPC singlemode, 3meter, riser rated patch cable, hand coiled, with pulling eye All Duplex Clipped custom assemblies are A to B polarity. A to A polarity is available upon request! MODE S S= Singlemode M= Multimode H= Hybrid P= Polarization Maintaining Fiber (Slow Axis) F= Polarization Maintaining Fiber (Fast Axis) LENGTH (IN METERS) X CABLE RATING RI NP= No Preference RI= OFNR (Riser) PL= OFNP (Plenum) LZ= LSZH (Low Smoke) UV= Polyethylene/Outdoor FIBER COUNT (Multi Fiber Only) 04 02=2Fiber 04=4 Fiber 06=6 Fiber 12=12 Fiber 24=24 Fiber 48=48 Fiber 72=72 Fiber 96=96 Fiber 144=144 Fiber *Specify Fiber Count not listed SPOOLING OPTIONS HC HC=Hand Coil SP = Spool PULLING EYE INSTALLED PE PE= Outside End Only PBE= Both Ends BREAKOUT BUILD-UP (Multi Fiber Only) Z3 Z9=900µm Z6=1.6mm Z1=1.8mm Z2=2.0mm Z3=3.0mm NEED TO YOUR EXACT SPECIFICATIONS. SIMPLEX PATCH CABLE UNCLIPPED DUPLEX PATCH CABLE LENGTH (+3"-/0") up to 5 meters >5m = +/- 10% CLIPPED DUPLEX PATCH CABLE Standard Polarity A to B / B to A DISTRIBUTION - INDOOR/OUTDOOR ASSEMBLY 2-144 Fiber (ex. 6 Fiber Assembly) NODE CABLE ASSEMBLY Epoxy Node Cable Standard Breakout = 1 meter LOOSE TUBE CABLE ASSEMBLY Standard Breakout = 1 meter ELIMENT™ MDC USCONEC ™ NEW HIGH DENSITY, 2 FIBER CONNECTORS US Conec's ELiMENT™MDC connector is a Very Small Form Factor (VSFF) duplex optical connector designed for termination of Multi-mode and Single-mode fiber cables up to 2.0mm in diameter. The MDC connector is manufactured with proven 1.25mm ferrule technology used in industry standard LC optical connectors, meeting IEC 61753-1 Grade B insertion loss requirements. Contains (2) 1.25 mm ceramic ferrules (ferrules same as LC). PART # DESCRIPTION PRICE 22082 9/125 SM UPC MDC 2 fiber connector, Blue, requires 1.6-2.0mm Round Cable $4.80 22083 9/125 SM APC MDC 2 fiber connector, Green, requires 1.6-2.0mm Round Cable 6.50 22084 OM3 50/125 MDC 2 fiber connector, Aqua, requires 1.6-2.0mm Round Cable 5.55 22236 OM4 50/125 MDC 2 fiber connector, Magenta, requires 1.6-2.0mm Round Cable 5.55 22237 OM5 50/125 MDC 2 fiber connector, Lime Green, requires 1.6-2.0mm Round Cable 4.80 21866 USConec 2 port SM MDC/MDC adapter, Blue. 4 dust plugs 7.25 21867 USConec 2 port SM APC MDC/MDC adapter, Green. 4 dust plugs 7.25 21868 USConec 2 port MM OM3 MDC/MDC adapter, Aqua. 4 dust plugs 7.25 21870 USConec 2 port MM OM4 MDC/MDC adapter, Magenta. 4 dust plugs 7.25 21869 USConec 2 port MM OM5 MDC/MDC adapter, Lime Green. 4 dust plugs 7.25 22524 USConec 2 port SM MDC/MDC adapter, Blue. 4 dust plugs 6.50 22525 USConec 2 port SM APC MDC/MDC adapter, Green. 6.50 22526 USConec 2 port MM OM3 MDC/MDC adapter, Aqua. 6.50 22527 USConec 2 port MM OM4 MDC/MDC adapter, Magenta. 6.50 22528 USConec 2 port MM OM5 MDC/MDC adapter, Lime Green. 6.50 22082 • Two 1.25mm ferrules in one connector housing • Push-pull boot for connector insertion and extraction • Simple polarity reversal with no exposed fibers • Meets IEC 61753-1 Grade B insertion loss requirements • Telcordia GR-326 and TIA-568 compliant • Designed for cables up to 2.0mm OD • MM, SM and SM APC available • 3x fiber cabling density over LC FEATURES
12 1.800.5000.FIS (347) | fiberinstrumentsales.com | @FISsales | /FISsales ASSEMBLIES | MPO/MTP CABLE ASSEMBLY MULTIMODE AND SINGLEMODE CUSTOMMPO/MTP TRUNK CABLE ASSEMBLY CONFIGURATOR: Use this chart to build your MPO/MTP custom cable assembly CABLE STYLE M MD = Micro Distribution HD = High Density Mirco Distribution R = Ribbon P/E X PE = Pulling Eye PBE = Pulling Eyes Both Ends BUILD UP BREAKOUT X Z9 = 900 Z2 = 2mm Z3 = 3mm X = None MODE M S = Singlemode M = Multimode CABLE FIBER COUNT 12 12 = 12-fiber 24 = 24 fiber 32= 32 fiber 36 = 36 fiber 48 = 48 fiber 72 = 72 fiber 144 = 144 fiber JACKET PL R = Riser PL = Plenum POLARITY A A =Type A B =Type B C =Type C D = 24 Fiber Type A E = 24 Fiber Type B U = Other (User Defined) LENGTH (IN METERS) 1 MPO/MTP FERRULE QUALITY S S = Standard * E = Elite * P = MTP Pro * F = Fast-Track MTP® FIBER 8 1 = 50µm MM - OM2 2 = 62.5µm MM - OM1 3 = 9µm SM - OS2 8 = 50µm 10Gig-OM3 * 9 = 9µm SM - ULTRA * 10 = 50µm 10Gig - OM4 * 12= 50µm10Gig - OM5 * Bend Insensitive The FIS MPO/MTP Module is a pre-terminated, pre-tested, rack mount module system allowing for a simple installation of MPO/MTP backbone cables with a transition to standard LC or SC connections. The FIS modules are designed to fit into enclosures with LGX slot configurations. Using a pre-terminated cable assembly in conjunction with modules within a rack allows for easier installation and simpler cable management. Contact your FIS sales representative today for further details or use the configurators below to construct the proper combination to meet any requirement. All stock cassettes are built using elite ferrules. MPO/MTP PRE-TERMINATED SYSTEMS BUILD YOUR OWN CUSTOMMPO/MTP MODULE / CASSETTE Use this chart to build a MPO/MTP module to your exact specifications. MODULE STYLE F1-MTP F1-MTP = MPO/MTP Cassette, LGX, Black FIBER TYPE OS2 OM1 = 62.5µm OM1, MM OM2 = 50µm OM2, MM OM3 = 50µm OM3, MM OM4 = 50µm OM4, MM OM5 = 50µm OM5, MM OS2 = 9µm OS2, SM MPO/MTP GENDER M M=Male F = Female MTP CASSETTE POLARITY A A =Type A (Default) AF=Type A Flipped B =Type B C =Type C D = 24 Fiber Type A E = 24 Fiber Type B U = Other (User Defined) FIBER COUNT 12 8 = 8 Fiber 12 = 12 Fiber 16 = 16 Fiber 24 = 24 Fiber 32 = 32 Fiber FRONT CONNECTOR LU Y = SC/PC YU = SC/UPC YA = SC/APC L = LC/PC LU = LC/UPC LA = LC/APC STANDARD FERRULES VS. ELITE FERRULES SPECIFICATIONS STANDARD FERRULES ELITE FERRULES Standard Singlemode MT Ferrule Standard Multimode MT Ferrule MM MT Elite® Multimode MT Ferrule SM MT Elite® Singlemode MT Ferrule Insertion Loss 0.25dB Typical (All Fibers) 0.75dB Maximum (Single Fiber) 1 0.20dB Typical (All Fibers) 0.60dB Maximum (Single Fiber) 2,3 0.1dB Typical (All Fibers) 0.35dB Maximum (Single Fiber) 2,3 0.10dB Typical (All Fibers) 0.35dB Maximum (Single Fiber) 1 Optical Return Loss >60dB (8° Angle Polish) >20dB >20dB >60dB (8° Angle Polish) Call Your Sales Representative for Additional Configurations NEW Connector Fast-Track MTP® Slim Design for Easier Installation CONNECTOR SIDE A (MTP STYLE ONLY)/ SIDE B MF12 LU YU = SC/UPC YA = SC/APC LU = LC/UPC LA = LC/APC 8U = ST/UPC 7U = FC/UPC 7A = FC/APC MT8 = MTP 8 Ferrule Male MT12 = MTP 12 Ferrule Male MT16 = MTP 16 Ferrule Male MT24 = MTP 24 Ferrule Male MT32 = MTP 32 Ferrule Male MF48 = MTP 48 Ferrule Male MF72 = MTP 72 Ferrule Male MF8 = MTP 8 Ferrule Female MF12 = MTP 12 Ferrule Female MF16 = MTP 16 Ferrule Female MF24 = MTP 24 Ferrule Female MF32 = MTP 32 Ferrule Female MF48 = MTP 48 Ferrule Female MF72 = MTP 72 Ferrule Female MC16M = MMC 16 Ferrule Male MC24M = MMC 24 Ferrule Male MC16F = MMC 16 Ferrule Female MC24F = MMC 24 Ferrule Female * Note: Choose two connector styles from the chart above one for Connector Side A and one for Connector Side B. Side A must be of a MTP style connector only. 24 FIBER MPO/MTP STRAIGHT POLARITY 24 FIBER MPO/MTP TYPE - B REVERSED POLARITY Key Up Key Up Flipped 24 Fiber MPO to MPO Polarity (Type B) Available using Ribbon & Micro Distribution Cabl e ailable using Ribbon & Micro Distribution Cabl ailable using R bbon & Micro Distribut on Cabl ail ble using Ribbon & Micro Distribut on Cabl Key Side A Channels 1. Blue 13. Blue 2. Orange 14. Orange 3. Green 15. Green 4. Brown 16. Brown 5. Slate 17. Slate 6. White 18. White 7. Red 19. Red 8. Black 20. Black 9. Yellow 21. Yellow 10. Violet 22. Violet 11. Rose 23. Rose 12. Aqua 24. Aqua Key Side B Channels 12. Blue 24. Blue 11. Orange 23. Orange 10. Green 22. Green 9. Brown 21. Brown 8. Slate 20. Slate 7. White 19. White 6. Red 18. Red 5. Black 17. Black 4. Yellow 16. Yellow 3. Violet 15. Violet 2. Rose 14. Rose 1. Aqua 13. Aqua Side A Side B Type B Key Up Key Up Flipped 24 Fiber MPO to MPO Polarity (Type B) Available using Ribbon & Micro Distribution Cabl e ailable using Ribbon & Micro Distribution Cabl ailable using R bbon & Micro Distribu on Cabl ail ble using Ribbon & Micro Distribut on Cabl Key Side A Channels 1. Blue 2. Orange ge 3. Green n 4. Brown wn 5. Slate 6. White e 7. Red 8. Black k 9. Yellow w 10. Violet t 11. Rose 12. Aqua a Key Side B Channels 12. Blue 24 11. Orange 23 10. Green 22 9. Brown 21 8. Slate 20 7. White 19 6. Red 18 5. Black 17 4. Yellow 16 3. Violet 15 2. Rose 14 1. Aqua 13 Key Up Key Up Flipped 24 Fiber MPO to MPO Polarity (Type B) Available using Ribbon & Micro Distribution Cabl e ailable using Ribbon & Micro Distribution Cabl ailable using R bbon & Micro Distribu on Cabl ail ble using Ribbon & Micro Distribut on Cabl Key Up Key Up Flipped 24 Fiber MPO to MPO Polarity (Type B) Availa le usi g Ribbon & Micro Distribution Cabl e aila le using Ribbon & Micro Distribution Cabl ailable using Ribbon & Micro Distribu on Cabl a lable using Ri bon & Micro Distribut on Cabl Key Side A Channels 1. Blue 13. Blue 2. Orange 14. Orange 3. Green 15. Green 4. Brown 16. Brown 5. Slate 17. Slate 6. White 18. White 7. Red 19. Red 8. Black 20. Black 9. Yellow 21. Yellow 10. Violet 22. Violet 11. Rose 23. Rose 12. Aqua 24. Aqua Key 12. Blue 24. Blue 11. Orange 23. Orange 10. Green 22. Green 9. Brown 21. Brown 8. Slate 20. Slate 7. White 19. White 6. Red 18. Red 5. Black 17. Black 4. Yellow 16. Yellow 3. Violet 15. Violet 2. Rose 14. Rose 1. Aqua 13. Aqua Type A Side A Side B Key Up Key Up Flipped 24 Fiber MPO to MPO Polarity (Type B) Available using Ribbon & Micro Distribution Cabl e ailable using Ribbon & Micro Distribution Cabl ailable using R bbon & Micro Distribu on Cabl ail ble using Ribbon & Micro Distribut on Cabl Key Side A Channels 1. Blue 13. Blue 2. Orange 14. Orange 3. Green 15. Green 4. Brown 16. Brown 5. Slate 17. Slate 6. White 18. White 7. Red 19. Red 8. Black 20. Black 9. Yellow 21. Yellow 10. Violet 22. Violet 11. Rose 23. Rose 12. Aqua 24. Aqua Key 12. Blue 24. Blue 11. Orange 23. Orange 10. Green 22. Green 9. Brown 21. Brown 8. Slate 20. Slate 7. White 19. White 6. Red 18. Red 5. Black 17. Black 4. Yellow 16. Yellow 3. Violet 15. Violet 2. Rose 14. Rose 1. Aqua 13. Aqua Key Up Flipped 24 Fiber MPO to MPO P Available using Ribbon & Micro Dist ailable using Ribbon & Micro Dis ailable using R bbon & Micro Distribu ail ble using Ribbon & Micro Distribut o Key Side A Channels 1. Blue 13. Blue 2. Orange 14. Orange 3. Green 15. Green 4. Brown 16. Brown 5. Slate 17. Slate 6. White 18. White 7. Red 19. Red 8. Black 20. Black 9. Yellow 21. Yellow 10. Violet 22. Violet 11. Rose 23. Rose 12. Aqua 24. Aqua Key Up Key Up Flipped 24 Fiber MPO to MPO Polarity (Type B) Available using Ribbon & Micro Distribution Cabl e ailable using Ribbon & Micro Distribution Cabl ailable using R bbon & Micro Distribu on Cabl ail ble using Ribbon & Micro Distribut on Cabl Key Side A Channels 1. Blue 13. Blue 2. Orange 14. Orange 3. Green 15. Green 4. Brown 16. Brown 5. Slate 17. Slate 6. White 18. White 7. Red 19. Red 8. Black 20. Black 9. Yellow 21. Yellow 10. Violet 22. Violet 11. Rose 23. Rose 12. Aqua 24. Aqua Key Side B Channels 12. Blue 24. Blue 11. Orange 23. Orange 10. Green 22. Green 9. Brown 21. Brown 8. Slate 20. Slate 7. White 19. White 6. Red 18. Red 5. Black 17. Black 4. Yellow 16. Yellow 3. Violet 15. Violet 2. Rose 14. Rose 1. Aqua 13. Aqua
13 /FISsales | @FISsales | fiberinstrumentsales.com | 1.800.5000.FIS (347) ASSEMBLIES | MPO/MTP CABLE ASSEMBLY MULTIMODE AND SINGLEMODE CUSTOM 12 FIBER MPO/MTP TO MPO/MTP TRUNK CABLE DIAGRAMS Use these diagrams to help build the cable you need to your exact specifications. 12 FIBER TYPE C MPO/MTP POLARITY P1 P3 P5 P7 P9 P11 P2 P4 P6 P8 P10P 12 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 P12 P10 P7 P5 P3 P1 P9 P11 P6 P4 P2 P8 P1 P3 P5 P7 P9 P11 P2 P4 P6 P8 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 P1 P1 2 2 P1 P1 0 0 P7 P5 P3 P1 P9 P11 P6 P4 P2 P8 White dot: Postion 1 White dot: Postion 1 White dot: Postion 1 White dot: Postion 1 Key Up to Key Down Adapter Key Up connector faces Key Up to Key Up Key Up to Key Up Rx Rx Tx Tx A-to-B Patch Cord A-to-B Patch Cord Fiber Cassette Fiber Cassette Optical Path Rotation in cable Key Up to Key Down Adapter 12 FIBER TYPE B MPO/MTP POLARITY Type B Reversed 12 Fiber MPO to MPO Polarity (Type B) Available using Ribbon & Micro Distribution Cabl e ailable using Ribbon & Micro Distribution Cabl ailable using R bbon & Micro Distribu on Cabl ail ble using Ribbon & Micro Distribut on Cabl Key Up Key Up Source channel: Meter channel: 1 2 3 4 5 6 7 8 9 10 11 12 11 10 9 8 7 5 4 3 2 1 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 Position 1 Position 12 Position 12 Position 1 12 6 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 P12 P10 P7 P5 P3 P1 P9 P11 P6 P4 P2 P8 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 P12 P10 P7 P5 P3 P1 P9 P11 P6 P4 P2 P8 White dot: Postion 1 White dot: Postion 1 Key Up to Key Up Adapter Key Up connector faces Key Up to Key Up Key Up to Key Up Tx A-to-B Patch Cord A-to-B Patch Cord Fiber Cassette Fiber Cassette Rx Tx Optical Path Key Up to Key Up Adapter P5 P7 P9 P11 P6 P8 P12 P10 P1 P2 P3 P4 P5 P7 P9 P11 P6 P8 P12 P10 P1 P2 P3 P4 12 FIBER TYPE A MPO/MTP POLARITY Key Up Key Down Source channel: Meter channel: 1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 10 11 12 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 Position 1 Position 12 Position 1 Position 12 Note: Fiber 1 is in position 1 at both ends of the cable Type A Straight Through 12 Fiber MPO to MPO Polarity (Type A ) Available using Ribbon & Micro Distribution Cabl e ailable using Ri bon & Micro Distribution Cabl olarity ( ailable us ng Ribbon & Micro Distribution Cabl ail ble using Ribbo & Micro D st ibution Cabl P1 P3 P5 P7 P9 P11 P2 P4 P6 P8 P10P 12 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 P12 P10 P7 P5 P3 P1 P9 P11 P6 P4 P2 P8 P1 P3 P5 P7 P9 P11 P2 P4 P6 P8 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 P1 P1 2 2 P1 P1 0 0 P7 P5 P3 P1 P9 P11 P6 P4 P2 P8 White dot: Postion 1 White dot: Postion 1 White dot: Postion 1 White dot: Postion 1 Key Up to Key Down Adapter Key Up connector faces Key Up to Key Up Key Up to Key Up Rx Rx Tx Tx A-to-B Patch Cord A-to-A Patch Cord Fiber Cassette Fiber Cassette Optical Path Rotation in cable Key Up to Key Down Adapter MD9MF12MF12SxxE12AXPL – Quantity 1 Trunk Cable (MPO/MTP PlenumTrunk cable Method A using MicroDistribution Singlemode, 12 Fiber cable with MTP/Female Elite – MTP/Female Elite connectors, “xx”= length ) F1MTP12OS2MT12ELUA - Quantity 2 Cassettes (one cassette for Side A and one for Side B 12 Fiber Type A Singlemode Cassette with 1 rear MPO/MTP -male elite port, 6 front LC duplex ports) X9CCSxxPLHC – Quantity 6 Patch Cables (Duplex A - B Plenum 1.6mm Singlemode Patch cord LC Duplex – LC Duplex , “xx”= length of hand coiled) X9CCSxxPLHC – Quantity 6 Patch Cables (Duplex A – A* Plenum 1.6mm Singlemode patch cord LC Duplex – LC Duplex plenum“xx”= length hand coiled) *Must specify A –A polarity MD8MF12MF12MxxE12BXPL – Quantity 1 Trunk Cable (MPO/MTP PlenumTrunk cable Method B using Micro-Distribution Multimode OM3, 12 Fiber cable with MTP/Female Elite – MTP/ Female Elite connectors, “xx”= length) F1MTP12OM3MT12ELUB - Quantity 2 Cassettes (one cassette for Side A and one for Side B 12 Fiber Type B Multimode OM3 Cassette with 1 rear MPO/MTP -male elite port, 6 front LC duplex ports) X8CCMxxPLHC – Quantity 12 Patch Cables (Duplex A - B Plenum 1.6mmMultimode OM3 Patch cord LC Duplex – LC Duplex , “xx”= length of hand coiled Type C Flipped Pairs 12 Fiber MPO to MPO Polarity (Type C) Available using Micro Distribution Cable Key Up Key Down Source channel: Meter channel: 1 2 3 4 5 6 7 8 9 10 11 12 2 1 3 6 5 8 7 10 9 12 11 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12 Position 1 Position 12 Position 1 Fibers Flipped Position 12 4 MD8MF12MF12MxxE12CXPL – Quantity 1 Trunk Cable (MPO/MTP PlenumTrunk cable Method C using Micro-Distribution Multimode OM3, 12 Fiber cable with MTP/Female Elite – MTP/ Female Elite connectors, “xx”= length) F1MTP12OM3MT12ELUC - Quantity 2 Cassettes (one cassette for Side A and one for Side B 12 Fiber Type C Multimode OM3 Cassette with 1 rear MPO/MTP -male elite port, 6 front LC duplex ports) X8CCMxxPLHC – Quantity 12 Patch Cables (Duplex A - B Plenum 1.6mmMultimode OM3 Patch cord LC Duplex – LC Duplex , “xx”= length of hand coiled
14 1.800.5000.FIS (347) | fiberinstrumentsales.com | @FISsales | /FISsales ASSEMBLIES | SPECIALTY OPTICAL ASSEMBLIES POLARIZATION MAINTAINING PATCH CABLE For polarization-sensitive applications, FIS offers PM patch cables with UPC or APC connector finishes. Available in 900µm and 3mm jacketed versions. Important specifications need to be discussed with FIS Sales Associate upon ordering, such as: Alignment (slow or fast axis) Fiber Specifications, Cable Jacket (900µm buffer or 3.0mm), whether or not the purchased PM assemblies will be used for splicing. Contact FIS for additional specifications and pricing on PM jumpers of various lengths. Specify Fibercore Limited PM fiber or Corning PM Fiber. PART # DESCRIPTION PRICE S-4-9A-9A-S-1-FIS Simplex FC/APC - FC/APC, Slow Axis, 3.0mm Jacketed, Blue, 1 Meter $95.00 S-4-9U-9U-S-1-FIS Simplex FC/UPC - FC/UPC, Slow Axis, 3.0mm Jacketed, Blue, 1 Meter 95.00 S-4-9U-9A-S-1-FIS Simplex FC/UPC - FC/APC, Slow Axis, 3.0mm Jacketed, Blue, 1 Meter 95.00 E2000 PATCH CABLE AND MATING SLEEVES FIS offers Singlemode E2000 2.8mm cable assemblies. The E2000 comes with an integrated shutter system to protect the user from high-power laser emissions, and protects the connector from contamination. Call for other configurations and lengths. PART # MFG DESCRIPTION PRICE S-3-EU-EU-S-1-FISC FIS Simplex 9/125 E2000/UPC to E2000/UPC 1 Meter $26.95 S-3-EU-EU-S-3-FISC FIS Simplex 9/125 E2000/UPC to E2000/UPC 3 Meter 27.65 S-3-EU-EU-S-5-FISC FIS Simplex 9/125 E2000/UPC to E2000/UPC 5 Meter 28.35 S-3-EA-EA-S-1-FISC FIS Simplex 9/125 E2000/APC to E2000/APC 1 Meter 27.95 S-3-EA-EA-S-3-FISCU FIS Simplex 9/125 E2000/APC to E2000/APC 3 Meter 28.65 F1-E2000 FIS E2000 to E2000 Singlemode Adapter Ceramic Sleeve 12.00 F1-E2000APC FIS E2000/APC to E2000/APC Singlemode Adapter Ceramic Sleeve 15.00 S-4-9U-9U-S-1-FIS FIS FIBER OPTIC TERMINATOR CONNECTORS Low Reflection Terminators are designed for use in unused ports and to reduce back reflection into fiber optic systems. Each connector is environmentally sealed for protection. Back Reflection APC = -65dB UPC = -55dB PART # DESCRIPTION PRICE F1-0071 FIS ST/UPC Terminator Connector $6.95 F1-2071 FIS FC/UPC Terminator Connector 6.95 F1-3071 FIS SC/UPC Terminator Connector 6.95 F1-2072 FIS FC/APC Terminator Connector 7.95 F1-3072 FIS SC/APC Terminator Connector 7.95 F1-4071 FIS LC/UPC Terminator Connector 6.95 F1-4072 FIS LC/APC Terminator Connector 7.95 FIS LOOPBACK MODULES Loopbacks are designed for testing, engineering and the burn-in stage of boards or other equipment. They provide system test engineers a simple but effective way of testing the transmission capability and receiver sensitivity of network equipment. PART # DESCRIPTION PRICE F1-SCLB9A SC Loopback SM 9/125µm Fiber $14.50 F1-LCLB9A LC Loopback SM 9/125µm Fiber 14.50 F1-LCLB62A LC Loopback MM 62.5/125µm Fiber 14.50 F1-LCLB50A LC Loopback MM 50/125µm Fiber 14.50 FIS COMPACT NODE CABLES (SERVICE CABLES) Fiber Instrument Sales’ Compact Node is an epoxy based optical node cable assembly. Designed for HFC applications and with the flexibility to fit aerial, pedestal and vault applications. Available in various custom configurations up to 12 fibers. PART # DESCRIPTION PRICE NC-3-BA-P-S-15-FIS-2 Node Cable 2 Fiber Loosetube Cable SM SC/APC – Pigtail, 15 Meters $125.00 NC-3-BA-P-S-15-FIS-4 Node Cable 4 Fiber Loosetube Cable SM SC/APC – Pigtail, 15 Meters 156.00 NC-3-BA-P-S-15-FIS-6 Node Cable 6 Fiber Loosetube Cable SM SC/APC – Pigtail, 15 Meters 190.00 NC-3-BU-P-S-15-FIS-2 Node Cable 2 Fiber Loosetube Cable SM SC/UPC – Pigtail, 15 Meters 119.00 NC-3-BU-P-S-15-FIS-4 Node Cable 4 Fiber Loosetube Cable SM SC/UPC – Pigtail, 15 Meters 150.00 NC-3-BU-P-S-15-FIS-6 Node Cable 6 Fiber Loosetube Cable SM SC/UPC – Pigtail, 15 Meters 184.00 F1-2071 NC-3-BA-P-S-15-FIS-6 F1-3071 F1-SCLB9A E2000/APC E2000/UPC F1-LCLB9A Mode Conditioning Patch Cable is used in conjunction with laser transmitters or VCSEL's for 1 Gb transmissions over FDDI fiber in fiber optic links to improve the transition bandwidth by the reduction of modal dispersion. These cords can be assembled in various configurations to meet your specific needs. Contact your FIS sales representative for pricing and delivery. Improve the performance of your network today. MODE CONDITIONING PATCH CABLE LC-SC MCP MULTIMODE 62.5/125µm PART # LENGTH PRICE F1-MCP-1-2-LC-SC 1 Meter $68.00 F1-MCP-3-2-LC-SC 3 Meters 70.00 F1-MCP-5-2-LC-SC 5 Meters 73.00 F1-MCP-10-2-LC-SC 10 Meters 78.00 LC-ST MCP MULTIMODE 62.5/125µm PART # LENGTH PRICE F1-MCP-1-2-LC-ST 1 Meter $68.00 F1-MCP-3-2-LC-ST 3 Meters 70.00 F1-MCP-5-2-LC-ST 5 Meters 73.00 F1-MCP-10-2-LC-ST 10 Meters 78.00 F1-MCP-1-2-LC-ST
15 /FISsales | @FISsales | fiberinstrumentsales.com | 1.800.5000.FIS (347) PACKAGED NETWORK COUPLER AND TREE COUPLER Housed and connectorized with your specified connector are 1X2 or 1X4 Multimode or Singlemode splitters. Also available in same packaging is Singlemode 1310/1550nmWave Division Multiplexer (WDM). Specify core/clad size, connector style, and split ratio. (Highest port count available is 1X4.) Other Configurations Available - Call FIS Representative. PART # DESCRIPTION PRICE PNC-3-S-2-50-YU-YU Packaged Network Coupler Box, Singlemode, 50/50 split, 1x2 SC/UPC Adapters $135.00 PNC-3-S-2-10-YU-YU Packaged Network Coupler Box, Singlemode, 90/10 split, 1x2, SC/UPC Adapters 135.00 PNC-3-S-4-EV-YU-YU Packaged Network Coupler Box, Singlemode, Even split, 1x4, SC/UPC Adapters 239.00 PNC-3-S-4-50-7U-7U RUGGEDIZED 2mm/3mm JACKETED COUPLERS/SPLITTERS Install these ruggedized splitters into outdoor or indoor enclosures. The 2mm or 3mm furcated fiber legs offer extra protection when technicians are working in compact areas. The splitter/couplers are housed in a small plastic case; furcated fiber legs are attached with or without connectors installed. Custom size jacketing/split ratios/connector styles available. PART # DESCRIPTION PRICE RSC-3-S-2-50-YA-YA-2 Ruggedized Splitter, SM, 1 x 2, 50/50 split, SC/APC-SC/APC, 2mm jacketing $76.95 RSC-3-S-2-45-YA-YA-2 Ruggedized Splitter, SM, 1 x 2, 55/45 split, SC/APC-SC/APC, 2mm jacketing 76.95 RSC-3-S-2-40-YA-YA-2 Ruggedized Splitter, SM, 1 x 2, 60/40 split, SC/APC-SC/APC, 2mm jacketing 76.95 RSC-3-S-2-30-YA-YA-2 Ruggedized Splitter, SM, 1 x 2, 70/30 split, SC/APC-SC/APC, 2mm jacketing 76.95 RSC-3-S-2-05-YA-YA-2 Ruggedized Splitter, SM, 1 x 2, 90/5 split, SC/APC-SC/APC, 2mm jacketing 76.95 RSC-1-S-2-50-Y-Y-3 Ruggedized Splitter, 50µm, 1 x 2, 50/50 split, SC/PC-SC/PC, 3mm jacketing 80.00 RSC-1-S-2-40-Y-Y-3 Ruggedized Splitter, 50µm, 1 x 2, 60/40 split, SC/PC-SC/PC, 3mm jacketing 80.00 RSC-1-S-2-50-Y-Y-3 ASSEMBLIES | COUPLERS/SPLITTERS INQUIRE FOR PRICING ON CIRCULATORS OR ISOLATORS WAVELENGTH DIVISION MULTIPLEXERS AWave Division Multiplexer (WDM) is a coupler that enables you to channel a signal to multiple devices operating at different wavelengths. PART # DESCRIPTION PRICE 250µm Z1WDM13550122UC 1x2 Sm Dual Window (1310/1550nm) WDM 250µm Fiber $19.95 900µm Z1WDM13500129UC 1x2 Sm Dual Window (1310/1550nm) WDM 900µm Fiber $21.95 SINGLEMODE DUAL WINDOW COUPLERS/SPLITTERS PART # DESCRIPTION PRICE 250µm Z1SDW13550122UC 1x2 (1310/1550nm) 50/50 Ratio $24.95 Z1SDW13510122UC 1x2 (1310/1550nm) 10/90 Ratio 24.95 Z1SDW13520122UC 1x2 (1310/1550nm) 20/80 Ratio 24.95 Z1SDW13530122UC 1x2 (1310/1550nm) 30/70 Ratio 24.95 Z1SDW13540122UC 1x2 (1310/1550nm) 40/60 Ratio 24.95 Z1SDW13550222UC 2x2 (1310/1550nm) 50/50 Ratio 24.95 900µm Z1SDW13550129UC 1x2 (1310/1550nm) 50/50 Ratio $24.95 Z1SDW13510129UC 1x2 (1310/1550nm) 10/90 Ratio 24.95 Z1SDW13520129UC 1x2 (1310/1550nm) 20/80 Ratio 24.95 Z1SDW13530129UC 1x2 (1310/1550nm) 30/70 Ratio 24.95 Z1SDW13540129UC 1x2 (1310/1550nm) 40/60 Ratio 24.95 Z1SDW13550229UC 2x2 (1310/1550nm) 50/50 Ratio 24.95 MULTIMODE COUPLERS/SPLITTERS (800-1600nm) PART # DESCRIPTION PRICE 250µm Z1MMC28550122C 1x2 62.5/125μm Coupler 50/50 Ratio 250µm Fiber $63.95 Z1MMC38550122C 1x2 50/125μm Coupler 50/50 Ratio 250µm Fiber 63.95 900µm Z1MMC28550129C 1x2 62.5/125μm Coupler 50/50 Ratio 900µm Fiber $63.95 Z1MMC38550129C 1x2 50/125μm Coupler 50/50 Ratio 900µm Fiber 63.95 Wavelength Division Multiplexing is a technology utilized in fiber optics that allows multiple laser sources to broadcast through a single fiber. AWDM enables a single fiber to broadcast Bi-Directionally and increase bandwidth by a factor of the number of light sources utilized. There are sub categories of WDM that refer to the number of allowable lasers (channels) used, each source is spaced equally by a defined separation of wavelength. WAVELENGTH DIVISION MULTIPLEXERS Dual Window Coupler/Splitter
16 1.800.5000.FIS (347) | fiberinstrumentsales.com | @FISsales | /FISsales ASSEMBLIES | BROADCAST / MILITARY & HARSH ENVIRONMENT FIS Blue provides specialized assemblies to the Military and Broadcast Industries. Count on them for custom broadcast or military grade tactical fiber optic cable assemblies with up to 24 fibers, in cables that are crush-resistant, resilient and with a thick layer of aramid strength members. The Kevlar within the cable is strong enough to withstand the weight of a truck, making these assemblies ideal for temporary field production, sporting events, and military operations. Call us today for more information and detailed specifications. Our cable assemblies can be terminated with a variety of specialized connectors such as Expanded Beam, TFOCA II® or SMPTE Connectors. These specialized connectors can also be paired with standard connectors (SC, LC, FC, ST, etc.). FIBERFOX 2CH & 4CH CABLE CONNECTORS The FIBERFOX 2CH & 4CH Cable connectors are expanded beam multimode hermaphroditic connectors suited for a vast array of applications, including Lighting, Network, PA, Video, Broadcast, Defense & Government, Railway and Petrochemical. The innovative design ensures its suitability for deployment in the toughest environments where constant performance and total reliability are critical. The connector is designed according to the MIL-DTL-83526 standard and fits to all other connectors with this standard. • Heavy-duty, connectors IP68 (even unprotected • No special cleaning or measurement tools required • Ø = 5mm, PUR flame-retardant, halogen-free, bend tolerant • Cables can be mated together directly, no couplers required • Ready-made up with connectors EBC1502 • Wear-free connectors, > 10,000 mating cycles without any maintenance PART # DESCRIPTION PRICE T-10-PF-PF-M-100-FISB-2 FIBERFOX Multimode 2-channel 100 Feet OM3 No Reel $1,164.44 T-10-PF-PF-M-100-FISB-2-RL FIBERFOX Multimode 2-channel 100 Feet OM3 GT-310 Reel 1,442.22 T-10-PF-PF-M-100-FISB-4 FIBERFOX Multimode 4-channel 100 Feet OM3 No Reel 1,417.78 T-10-PF-PF-M-100-FISB-4-RL FIBERFOX Multimode 4-channel 100 Feet OM3 GT-310 Reel 1,695.56 *Different cable lengths available upon request. R Please Call For Additional Pricing. opticalCON® ADVANCED MTP® FIBERFOX 2CH Cable Connector FIBERFOX 4CH Cable Connector ADVANCED DUO ADVANCED MTP® ADVANCED QUAD opticalCON® ADVANCED MTP® The opticalCON MTP® cable connectors are characterized by the robust all-metal housing and the heavy-duty strain relief. The innovative spherical dust shutter protects the fiber from contamination and minimizes maintenance. The color-coded cable connectors are pre-assembled and available in a variety of mobile field cables. • For Point-to-Point multichannel routing • Dust and water resistant according to IP65 in mated condition • Rugged 12-channel fiber optic connection system • Innovative spherical shutter guarantees low maintenance PART # DESCRIPTION PRICE LT-3-OM-OM-S-100-FISB-12 opticalCON® MTP Singlemode 12-channel 100 Feet No Reel $1,921.00 LT-3-OM-OM-S-100-FISB-24 opticalCON® MTP Singlemode 24-channel 100 Feet No Reel 2,283.00 *Different cable lengths available upon request. SMPTE 311M Cable Assembly • Waterproof acc. to IP65 safety standard in mated condition • opticalCON multimode fiber cables offer laser and bend optimized OM3 fibers • Cable connector features rugged all metal housing and heavy duty cable retention • Reliable Push-Pull locking mechanism • Available in different packaging versions • Ruggedized and dirt protected fiber optic connection system • 2-pole military approved robust and light weight mobile field cable with multi- or single mode fibers • Accommodates standard optical LC-Duplex connectors • Excellent dust and dirt protection due to automatic sealing shutter with silicone gasket • Easy to clean, no special tools required PART # DESCRIPTION PRICE T-3-OD-OD-S-100-FISB-2 opticalCON® Duo Singlemode 2-channel 100 Feet No Reel $799.57 T-3-OD-OD-S-100-FISB-2-RL opticalCON® Duo Singlemode 2-channel 100 Feet GT-310 Reel 970.00 T-3-OQ-OQ-S-100-FISB-4 opticalCON® Quad Singlemode 4-channel 100 Feet No Reel 897.00 T-3-OQ-OQ-S-100-FISB-4-RL opticalCON® Quad Singlemode 4-channel 100 Feet GT-310 Reel 1,082.00 *Different cable lengths available upon request. opticalCON® ADVANCED DUO AND QUAD The opticalCON system is based on LC-Duplex connectors but eliminates its weakness and guarantees a safe, dust-protected and rugged connection. Being compatible to conventional LC connectors the opticalCON DUO offers the choice of using costeffective LC cables or the rugged opticalCON cable assembly for mobile applications. The opticalCON DUO is the ideal solution for equipment connections and system integration offering LC compatibility on chassis connector front and rear. The opticalCON QUAD is based on the proven opticalCON DUO connection system but with four channels it is optimized for Point-to-Point interconnections and multi-channel routing applications. The system copes with the increasing need for fiber optic channels. • opticalCON multimode fiber cables offer laser and bend optimized OM3 fibers • Innovative spherical shutter guarantees low maintenance • Ruggedized and dirt protected fiber optic connection system • For Point-to-Point multichannel routing • Dust and water resistant according to IP65 in mated condition opticalCON® ADVANCED DUO FEATURES opticalCON® ADVANCED QUAD FEATURES PART # DESCRIPTION PRICE BC-3-FUW-PUW-S-100-FISB-2 LEMO SMPTE Assembly PUW (receptacle) to FUW (plug) 100 feet $1,045.00 *Different cable lengths available upon request. SMPTE 311M CABLE ASSEMBLIES These rugged stainless steel SMPTE connectors ensure a very long product life. Cable assemblies utilize two Singlemode fiber contacts, two power contacts and two signal contacts. Cable assembles are available with multiple configurations including panel mount receptacles and plugs. • Quick Push-Pull Self Latching System • Stainless Steel for Harsh Environments • Complies with SMPTE Signal Requirements • Popular HDTV Connection on Cameras and Panels
