Standard LC Connectors
The LC connector licensed by Lucent Technologies provides a pull-proof design and small size perfect for high-density applications. Available in simplex or duplex versions. The LC connector is provided with a 1.25mm zirconia ferrule. The LC also incorporates a unique latching mechanism providing stability in system rack mounts.
FIS LC CONNECTORS
Type |
Boot Size |
Ferrule
|
Ferrule |
Part # |
| Simplex-MM | 3mm | 128µm | Zirconia | F1-5066 |
| Simplex-MM OM3/OM4 - Aqua | 3mm | 126µm | Zirconia | F1-5066AAQ |
| Simplex-MM OM3/OM4 - Aqua | 1.6-2mm | 128µm | Zirconia | F1-506616AAQ |
| Simplex-MM | 1.6-2mm | 128µm | Zirconia | F1-506616 |
| Simplex-MM OM4 - Magenta | 1.6-2mm | 128µm | Zirconia | F1-506616M |
| Simplex-MM | 900µm | 128µm | Zirconia | F1-5066900 |
| Simplex-SM | 3mm | 126µm | Zirconia | F1-5069 |
| Simplex-SM | 1.6-2mm | 126µm | Zirconia | F1-506916 |
| Simplex-SM | 900µm | 126µm | Zirconia | F1-5069900 |
| Simplex APC | 3mm | 126µm | Zirconia | F1-5069APC |
| Simplex APC | 900µm | 126µm | Zirconia | F1-5069900APC |
| Duplex-MM | 3mm | 128µm | Zirconia | F1-6066 |
| Duplex-MM | 1.6-2mm | 128µm | Zirconia | F1-606616 |
| Duplex-MM OM3 - Magenta | 1.6-2mm | 128µm | Zirconia | F1-606616M |
| Duplex-MM OM3/OM4 - Aqua | 3mm | 128µm | Zirconia | F1-6066AQ |
| Duplex-MM OM3/OM4 - Aqua | 1.6-2mm | 128µm | Zirconia | F1-606616AQ |
| Duplex-SM | 3mm | 126µm | Zirconia | F1-6069 |
| Duplex-SM | 1.6-2mm | 126µm | Zirconia | F1-606916 |
| Duplex-SM | 900µm | 126µm | Zirconia | F1-6069900 |
| Anaerobic-MM | 3mm | 128µm | Zirconia | F1-5066AR |
| Duplex Mini LC-SM - Blue * | 1.6mm | 126µm | Zirconia | F1-6067 |
| Duplex Mini LC-MM OM3/OM4 - Aqua * | 1.6mm | 127µm | Zirconia | F1-6068AQ |
| Duplex Mini LC-MM - Beige * | 1.6mm | 127µm | Zirconia | F1-6068 |
*The Mini LC Connector is designed with a narrow ferrule pitch (5.25mm) to work with the Mini SFP (mSFP) transceiver.
CORNING LC CONNECTORS
Type |
Boot Size |
Ferrule
|
Ferrule |
Part # |
| Simplex-MM | 3.0mm | 125.5µm | Zirconia | 95-100-LCSP |
| Simplex-MM | 2.0mm | 125.5µm | Zirconia | 95-100-LCSP2 |
Description |
Part # |
| LC Clips(each) - Simplex to duplex converters | TRIGGER-BP-D |
MOLEX LC CONNECTORS
Type |
Boot Size |
Ferrule
|
Ferrule |
Part # |
| Simplex-SM | 900µm | 126µm | Zirconia | 106024-5500 |
| Simplex-MM | 3mm | 127µm | Zirconia | 106024-3259 |
| Simplex-SM | 3mm | 126µm | Zirconia | 106024-5259 |
FIS BULK EPOXY STYLE CONNECTORS (Buy Bulk and Save)
FIS multimode and singlemode ST, SC, LC and FC connectors utilize high quality zirconia ferrules. Bulk packaged in lots of 100 pieces, these connectors offer the best value in performance and cost savings. Provided with 3mm or 900µm boots.
Description |
Part # |
| FIS MM LC Connector with 3mm boots - (100 pk.) | F1-5066-100 |
| FIS SM LC Connector with 3mm boots - (100 pk.) | F1-5069-100 |
| FIS MM 10 Gig LC Connector with 3mm boots - (100 pk.) | F1-5066AQ-100 |
| FIS MM LC Connector With 900um Boots (100pk) | F15066900100 |
| FIS SM LC Connector With 900um Boots (100pk) | F15069900100 |
| FIS MM LC Connector With 900um Boots (100pk) | F12073900100 |
| FIS SM LC Connector With 900um Boots (100pk) | F12070900100 |
Note: Connectors Available In 900µm Versions
