Fiber Optic Outdoor Closures

This FIS Dome Closure is for aerial or below grade.  It can be wall mounted and 4 cable entry/exit ports.   Capacity is 144 single fusion splices and tray for ribbon splicing & PLC splitters.

This FIS Outside Plant Direct Burial Closure offers the perfect choice for low fiber count distribution applications involving butt and inline installations. The compact size and rugged design allow the closure to be deployed in below grade, aerial and buried installations. Dimensions: 21” L x 8” W x 4” H Weight: 9lbs.

The Daisylink™ family of optical drop terminals utilize Factory installed optical splitters specifically designed to support the optical power requirement at the drop port. The family is designed for Aerial or Below grade high- or low-density distribution network applications. Products utilize factory industry available non-proprietary optical connectorized flat drops to connect terminal to terminal along a route without the need for multifiber cable and hardware. Inside the family of drop terminals are factory equipped with a specific uneven power ratio splitter designed for the location ensuring that the proper optical output is achieved. The product allows for a selection of uneven optical splitters from 1/99, 2/98, 3/97, 5/95, 10/90, 15/85, 20/80, 25/75, 30/70 etc.

The OSP Distribution 8 Port Enclosure is uniquely designed to accept a wide range of distribution and drop cables to accommodate any FTTx application. This “plug-n-play” style enclosure is specifically designed to accept 8 pre-terminated drop cables and up to 60 core splices. The Enclosure includes (5) 12ct Splice Trays, 8 Drop Cable ports, 4 Feeder Ports (5mm-10mm) and all mounting hardware. Dimensions 13.5"(h) x 7.75"(w) x 5.0"(d). * LC/APC's Available

FIS Drop Termination Enclosure provides maximum protection at the fiber splice point and distribution of drop fibers. This “plug-n-play” style enclosure is specially designed to accommodate 16 pre-terminated fiber drop cables. The outer case is constructed of chemical resistant, anti aging material. Splice trays are able to accommodate PLC Splitters, and/or up to 24 individual splices. Maximum of (6) 24ct splice trays per enclosure. Dimensions 13.5"(h) x 8.75"(w) x 5.0"(d). * LC/APC's Available

Ideal for restoring service to customers quickly during service outages. One side of the fiber is pre-prepped into the splice case to speed up restoration of service. The kit includes 1000’ of 48 Fiber Dry Loose Tube Cable with Corning Bend Insensitive SMF28 Ultra Fiber, Spooled onto a Re-deployable Reel on wheels, 75’ of the cable is spooled onto the inside flange. Also includes 2 Commscope FOSC-450A Splice Enclosures with (2) 24 Fiber Splice Trays each. Dimensions are 31.5"h x 31.5"w x 16”d.

The FIS Flexible Cable Splice Protector is an ideal solution for protecting fiber optic splices in challenging field conditions. This rugged, easy-to-install splice protector accommodates up to 12 splices with mini or micro protection sleeves, protecting them from moisture, vibration, shock and other adverse environmental conditions.

This family of closures offers a wide variety of applications from aerial to direct burial installations.

This family of closures offers a wide variety of applications from aerial to direct burial installations. Closure styles utilize the LOCK-TAPE and C-Cement sealing technology which experienced installers of copper and fiber optics are familiar.

The new COYOTE® ATC is Preformed Line Products’ first purpose-built aerial closure system focused to support the drop distribution network without the need for specialized drop cable assemblies. The closure features a unique dual chamber design with independent access to the splice/slack storage chamber and to the drop connection chamber. Inside the closure is a large slack storage area and splice tray system which support single fusion, mass fusion, mechanical splice protectors or splitter technology.

COMMSCOPE ACCESSORIES & SPLICE TRAYS

Commscope splice trays are manufactured for specific style closures. Be sure to match the type of closure to correct splice tray. Trays range from 12 count to 72 count single fiber splices.

Corning Fiber Optic Splice Closure 2178 is engineered to meet common needs and field conditions, with different sizes to accommodate varying splice counts. 2178 Closures are made of a tough chemical-resistant material and have a gasket seal, making them ideal for a wide variety of applications. All 2178 closures are designed to be easy to install, easy to use and easy to re-enter.

CORNING FIBER OPTIC SPLICE TRAYS AND OSP ACCESSORIES FOR 2178 SERIES

APEX-2S

Dimensions: 20” x 12”, Weight 22lbs(no trays), Splice Capacity 216 Single/432 Mass, Tray Capacity is 6, Single Port Cable OD 10-28mm, Multi-Drop Port Cable OD 5-9.9mm.

APEX-2

Dimensions: 25” x 12”, Weight 25lbs(no trays), Splice Capacity 432 Single/864 Mass, Tray Capacity is 6, Single Port Cable OD 10-28mm, Multi-Drop Port Cable OD 5-9.9mm.

This aerial weather tight fiber optic splice closure is for small to medium counts up to 72 fiber (or 288 ribbon fiber). Splice trays are available for single, mass or mechanical splicing. Splice Trays Not Included

This sealed dome closure is for medium count fiber splicing up to 96 fibers (288 ribbon) in a butt configuration. Can be utilized for aerial or underground applications where a sealed closure is required. Requires no tools for re-entry. Splice Trays Not Included
